3700A

Triconex 3700A AI Module | 32-Point Voltage/Current Input

In stock (20 units), ready to be shipped

  • Manufacturer: Invensys Triconex

  • Product No.: 3700A

  • Product Type: Analog Input Module

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 800g

  • Shipping port: Xiamen

  • Warranty: 12 months

30-Day Return Policy · 12-Month Warranty
  • Fast Delivery
  • 24/7 Support
  • Quality Assurance

Description

Product Introduction

The Triconex 3700A Analog Input Module delivers high-performance signal acquisition for critical process control systems. This 32-channel module features Triple Modular Redundant architecture for maximum reliability. The 3700A ensures accurate data conversion with comprehensive diagnostics in demanding industrial environments.

Core Specifications

  • Manufacturer: Triconex
  • Model Number: 3700A Analog Input Module
  • Product Type: TMR Analog Input Module
  • Input Channels: 32 differential, DC-coupled points
  • Input Voltage: 0-5VDC range with +6% tolerance
  • Update Rate: 55 milliseconds per scan
  • Resolution: 12-bit conversion precision
  • Accuracy: <0.15% of Full Scale Range (0° to 60°C)
  • Color Code: Yellow for visual identification

Electrical Performance

  • Input Resistance: 30 MΩ minimum DC load
  • Power-Off Resistance: 30 KΩ typical DC
  • Common Mode Rejection: -80 dB typical (DC-100Hz)
  • Common Mode Range: -12V to +12V peak
  • Leg-to-Leg Isolation: 200 KΩ typical
  • Current Input: 0-20 mA with 250Ω shunt resistor
  • Overvoltage Protection: 150 VDC/115 VAC continuous

Signal Processing

  • Normal Mode Rejection: -3 dB @ 8Hz
  • Frequency Response: -17 dB @ 60Hz
  • Noise Immunity: -23 dB @ 120Hz
  • Three independent input channels
  • Mid-value selection algorithm
  • Digital conversion of variable voltage signals
  • Data transmission to main processors

Common Questions

  • What is the input voltage range?

0-5VDC with +6% tolerance for signal inputs.

  • How many input channels provided?

32 differential DC-coupled input channels.

  • What is the module update rate?

55 millisecond update rate for all channels.
