CC-TAIM01 Honeywell Low Level Analog Input Module

Honeywell CC-TAIM01 Low-Level Analog Input Module

The Honeywell CC-TAIM01 is a high-precision analog input module designed for accurate measurement of low-level signals. It is ideally suited for connecting temperature sensors like RTDs and thermocouples, as well as other millivolt sources, in demanding process control applications.

Technical Specifications

• Brand & Model: Honeywell, CC-TAIM01
• Product Type: Low-Level Analog Input Module
• Availability: In Stock
• Input Signal Types: RTD (Pt100, Pt1000), Thermocouple (J, K, T, E, etc.), mV (0-100mV), mA (0-20mA)
• Resolution: 16-bit analog-to-digital conversion
• Accuracy: ±0.05% of reading for RTD/mA; ±0.5°C for thermocouple
• Input Impedance: > 10 MΩ (voltage inputs)
• Common Mode Rejection: > 120 dB at 50/60 Hz
• Update Rate: 4 conversions per second per channel (typical)
• Cold Junction Compensation: Integrated for thermocouple inputs
• Channel-to-Channel Isolation: 250 V AC

Installation & Packaging

• Installation: Install the CC-TAIM01 module in its designated slot on the system rack. Connect field sensor wiring (using appropriate 2, 3, or 4-wire connections for RTDs) to the module's front terminals, ensuring correct polarity for thermocouples.
• Packaging: Each CC-TAIM01 module ships individually. We ship via reliable carriers such as FedEx, UPS, or DHL.

FAQ

• Q: What types of temperature sensors does this module support?
  A: The CC-TAIM01 supports a wide range, including 2, 3, or 4-wire RTDs (like Pt100) and various thermocouple types (J, K, T, E, N, R, S, B). Each channel is software-configurable for the specific sensor type.
• Q: What is cold junction compensation and why is it important?
  A> Cold junction compensation (CJC) automatically measures and corrects for the temperature at the module's terminal block where the thermocouple wires connect. This is critical for thermocouple accuracy, as the voltage they generate depends on the temperature difference between the measuring and reference (cold) junctions.
• Q: Can I mix RTD and thermocouple inputs on the same module?
  A> Yes, the CC-TAIM01 is a universal analog input. Each of its channels can be independently configured for a different sensor type (RTD, TC, mV, or mA), providing maximum application flexibility from a single module.
