PP865A

PP865A ABB 3BSE042236R2 | 15 Inch Touch Panel 24VDC

Skladda bar (12 sany), ibermek üçin taýýar

  • Manufacturer: ABB

  • Product No.: PP865A

  • Product Type: Touch Panel

  • Product Origin: Sweden

  • Payment:T/T, Western Union

  • Weight: 3500g

  • Shipping port: Xiamen

  • Warranty: 12 months

30 günlük yzyna gaýtaryş syýasaty · 12 aýlyk kepillik
  • Çalt eltip berme
  • 24/7 goldaw
  • Hil üpjünçiligi

Düşündiriş

Product Overview

ABB PP865A 3BSE042236R2 Touch Panel is a 15-inch operator interface for industrial control systems. This resistive touch panel delivers 1024 x 768 resolution with 400 cd/m² brightness. It operates on 24 VDC with IP65 front panel protection.

Brand & Model

Brand ABB
Model PP865A 3BSE042236R2
Type Touch Panel

Technical Specifications

Display Size 15 inches
Resolution 1024 x 768 pixels
Brightness 400 cd/m²
Touch Technology Resistive Touch
Operating Voltage 24 VDC
Current Consumption Max 1.5 A
Power Consumption Max 36 W
Protection Rating IP65 (front panel)
Operating Temperature 0°C to 50°C (32°F to 122°F)
Storage Temperature -20°C to 70°C (-4°F to 158°F)
Weight Approx. 3.5 kg (7.7 lbs)

Installation Guide

Mount the PP865A in a panel cutout with IP65 sealing. Supply 24 VDC power with max 1.5 A current. Ensure ambient temperature stays between 0°C and 50°C. The resistive touch screen responds to gloved or stylus input. Keep the front panel clean for optimal touch sensitivity.

Engineering Advantages

The ABB PP865A delivers 1024 x 768 resolution for clear operator graphics. 400 cd/m² brightness ensures visibility in well-lit control rooms. IP65 front protection resists dust and water ingress. Low power consumption at max 36 W reduces heat load in control cabinets. Resistive touch technology works with safety gloves.

FAQs

Q1: What communication protocols does the PP865A support?
A1: The PP865A supports ABB's S800 I/O and AC800M controller communication via Ethernet and serial interfaces.

Q2: Is the PP865A compatible with Panel Builder 800?
A2: Yes. The PP865A is programmed using ABB Panel Builder 800 or Automation Builder software.

Q3: Can the brightness be adjusted?
A3: Yes. The 400 cd/m² brightness is adjustable via software settings for different lighting conditions.
