GE EX2100 IS200ERBPG1ACA Regulator Backplane PCB

Skladda bar (17 sany), ibermek üçin taýýar

  • Manufacturer: General Electric

  • Product No.: IS200ERBPG1ACA

  • Product Type: Backplane Module

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 500g

  • Shipping port: Xiamen

  • Warranty: 12 months

30 günlük yzyna gaýtaryş syýasaty · 12 aýlyk kepillik
  • Çalt eltip berme
  • 24/7 goldaw
  • Hil üpjünçiligi

Düşündiriş

GE EX2100 Exciter Regulator Backplane Board (IS200ERBPG1ACA)

The General Electric IS200ERBPG1ACA is an Exciter Regulator Backplane (ERBP) board developed for GE EX2100 excitation control systems and Speedtronic Mark VI turbine controls. Serving as the central interconnect hub within the exciter rack, this module provides signal routing and power distribution for internal cards such as DSPX, ACLA, ERIO, ERDD, and EPSM. Built with an open rectangular metal enclosure, perforated airflow panels, and mounting flanges, the board measures 8.26 x 4.19 cm (3.25 x 1.65 in) and weighs approximately 0.50 kg (1.1 lbs). It includes 3U/6U 96-pin and 128-pin VME-style DIN backplane connectors, a board ID serial bus, and master selection jumpers for simplex or redundant regulator setups.

Key Performance Advantages

Features dynamic board ID tracking for automated serial/revision identification, front auxiliary power outputs for cooling fans, and flexible master selection jumpers to configure single or dual-redundant exciter systems. Fully supports industrial communication via Modbus, Ethernet, and serial interfaces to integrate smoothly with CIMPLICITY HMI platforms.

Technical Specifications

Manufacturer & Series General Electric / Speedtronic Mark VI & EX2100 Excitation
Functional Part / Acronym IS200ERBPG1ACA / ERBP (Exciter Regulator Backplane)
Backplane Connectors 3U and 6U (96-pin or 128-pin DIN Backplane Connectors)
Dimensions & Weight 8.26 x 4.19 cm (3.25 x 1.65 in) / Approx. 0.50 kg (1.1 lbs)
Channels & Signal Range 12 Channels / 4–20 mA Input Span / 0–20 mA Analog Output
Common Mode Voltage & Resistance ±5 V Common Mode Voltage / 15 Ω Maximum Lead Resistance
Operating Temperature -30 °C to +65 °C (-22 °F to +149 °F)
Control Configurations Selectable Simplex or Dual Redundant Operation via Jumpers

Installation & Handling Guidelines

  • Rack Mounting & Airflow: Secure the ERBP module using the flanged mounting holes in the central control enclosure. Ensure fan assemblies and perforated casing openings remain unobstructed for optimal thermal dissipation.
  • Board Insertion & Jumper Setup: Carefully align option cards (DSPX, ERIO, ACLA) with the 96/128-pin DIN connectors. Set master selection jumpers according to system requirements for simplex or redundant architectures prior to power-up.
  • Power Connections & ESD Precautions: Connect front auxiliary power connectors for fan output and external boards. Ground all handling personnel with ESD wrist straps to protect sensitive backplane bus circuitry.

Frequently Asked Questions

Q1: Has EMC filter?
A1: N/A (backplane board).

Q2: Key feature vs PF523?
A2: Board ID bus & VME slots.

Q3: Drives 3-phase motors?
A3: Interconnects exciter boards.

🏷️ Tags: Backplane Module GE Mark VIe General Electric
