330104-00-02-15-02-00

Bently Nevada | 330104-00-02-15-02-00 8mm Probe

Skladda bar (19 sany), ibermek üçin taýýar

  • Manufacturer: Bently Nevada

  • Product No.: 330104-00-02-15-02-00

  • Product Type: Proximity Probe

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 250g

  • Shipping port: Xiamen

  • Warranty: 12 months

30 günlük yzyna gaýtaryş syýasaty · 12 aýlyk kepillik
  • Çalt eltip berme
  • 24/7 goldaw
  • Hil üpjünçiligi

Düşündiriş

Bently Nevada 330104-00-02-15-02-00 3300 XL 8mm Probe

Product Overview

Bently Nevada 330104-00-02-15-02-00 is a 3300 XL 8 mm proximity probe with M10 x 1 thread and armor. Unthreaded length 00 mm. Overall case length 20 mm. Total length 1.5 metre (4.9 feet). Miniature coaxial ClickLoc connector with standard cable. No agency approval required. Probe weight 0.25 kg.

Model Number Breakdown

Option Code Description
330104 3300 XL 8 mm Probe, M10 x 1 thread, with armor
00 Unthreaded length 00 mm
02 Overall case length 20 mm
15 Total length 1.5 metre (4.9 feet)
02 Miniature coaxial ClickLoc connector, standard cable
00 Not required

Technical Specifications

Parameter Value
Manufacturer Bently Nevada
Product Number 330104-00-02-15-02-00
Probe Type 3300 XL 8 mm
Thread Type M10 x 1
Armor With armor
Unthreaded Length 00 mm
Overall Case Length 20 mm
Total Length 1.5 metre (4.9 feet)
Connector Type Miniature coaxial ClickLoc
Agency Approval Not required
DC Resistance (1.5m) 7.73 ± 0.50 ohms
Proximitor Supply Voltage -17.5 to -26 V DC
Supply Sensitivity Less than 2 mV per volt change
Output Resistance 50 Ω
Probe Tip Material Polyphenylene sulfide (PPS)
Probe Case Material AISI 303 or 304 Stainless Steel
Pressure Seal Viton O-ring
Weight 0.25 kg

Key Features

  • M10 x 1 threaded probe with armor protection
  • 1.5 metre total length with 20 mm case
  • Miniature coaxial ClickLoc connector
  • PPS probe tip with AISI 303 or 304 stainless steel case
  • Viton O-ring pressure seal
  • 50 Ω output resistance
  • No agency approval required for this configuration

FAQs

Q1: What is the probe weight?
A1: 0.25 kg.

Q2: What is the probe DC resistance at 1.5 metre?
A2: 7.73 ± 0.50 ohms from center to outer conductor.

Q3: What is the output resistance and supply sensitivity?
A3: 50 Ω output resistance. Less than 2 mV change per volt input change.
