330101-00-60-10-01-05

Bently Nevada 330101-00-60-10-01-05 3300 XL 8mm Probe | 1m

Skladda bar (11 sany), ibermek üçin taýýar

  • Manufacturer: Bently Nevada

  • Product No.: 330101-00-60-10-01-05

  • Product Type: Proximity Probe

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 323g

  • Shipping port: Xiamen

  • Warranty: 12 months

30 günlük yzyna gaýtaryş syýasaty · 12 aýlyk kepillik
  • Çalt eltip berme
  • 24/7 goldaw
  • Hil üpjünçiligi

Düşündiriş

Product Overview

The Bently Nevada 330101-00-60-10-01-05 is a 3300 XL 8 mm proximity probe for vibration and position monitoring. Features 3/8‑24 UNF thread without armor. 6.0 inch overall case length, 1.0 meter total length. Miniature coaxial ClickLoc connector with connector protector. Weight: 0.323 kg (11.4 oz). Made in USA.

Core Advantages

Robust Mechanical Design

Patented TipLoc molding for secure probe tip bond. CableLoc design provides 330 N (75 lbf) pull strength. Optional FluidLoc cable option prevents oil leakage.

Wide Temperature Range

Standard probe operates from -52°C to +177°C. Extended temperature range option available for higher temperature applications.

High Accuracy

Incremental Scale Factor: 7.87 V/mm (200 mV/mil) ±5% for 1m systems. Linear range from 0.25 to 2.3 mm (10 to 90 mils).

Specifications

Parameter Value
Part Number 330101-00-60-10-01-05
Manufacturer Bently Nevada
Model 3300 XL 8 mm Probe
Thread Type 3/8‑24 UNF (without armor)
Unthreaded Length 0.0 in
Overall Case Length 6.0 in
Total Length 1.0 m (3.3 ft)
Connector Type Miniature coaxial ClickLoc with protector
Agency Approvals CSA, ATEX, IECEx
Linear Range 0.25–2.3 mm (10–90 mils)
Recommended Gap (Radial Vibration) -9 Vdc (~1.27 mm / 50 mils)
Scale Factor (1m system) 7.87 V/mm (200 mV/mil) ±5%
DSL (1m system) ±0.025 mm (±1 mil)
Probe Tip Material Polyphenylene sulfide (PPS)
Probe Case Material AISI 303/304 SST
Operating Temp (Standard) -52°C to +177°C
Cable Pull Strength 330 N (75 lbf)
Field Wiring Length 305 m (1,000 ft) max
Relative Humidity Tolerance <3% ASF change @ 93% RH (56 days)
Weight 0.323 kg (11.4 oz)

Installation Tips

Gap Setting

Set recommended gap to -9 Vdc (~1.27 mm / 50 mils) for radial vibration monitoring.

Field Wiring

Use 3‑conductor shielded triad cable, 0.2–1.5 mm² (16–24 AWG). Maximum 305 meters between Proximitor and monitor.

Temperature Considerations

Avoid exposing probe below -34°C as it may cause pressure seal failure. Observe operating limits.

Why Choose 330101-00-60-10-01-05?

Bently Nevada 3300 XL series reliability. TipLoc and CableLoc technologies ensure durability. ClickLoc connector provides secure connections. CSA/ATEX/IECEx approvals for global use. 8mm design offers thicker encapsulation and robust case.

FAQs

Q1: What approvals does this probe carry?
A1: CSA, ATEX, and IECEx certifications.

Q2: What is the linear range?
A2: 0.25 to 2.3 mm (10 to 90 mils), approximately -1 to -17 Vdc.

Q3: What is the maximum field wiring length?
A3: 305 meters (1,000 feet) between Proximitor and monitor.
