330101-00-40-10-02-05

Bently Nevada 330101-00-40-10-02-05 8mm Probe ClickLoc

Skladda bar (22 sany), ibermek üçin taýýar

  • Manufacturer: Bently Nevada

  • Product No.: 330101-00-40-10-02-05

  • Product Type: Proximity Probe

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 323g

  • Shipping port: Xiamen

  • Warranty: 12 months

30 günlük yzyna gaýtaryş syýasaty · 12 aýlyk kepillik
  • Çalt eltip berme
  • 24/7 goldaw
  • Hil üpjünçiligi

Düşündiriş

330101-00-40-10-02-05 Bently Nevada 3300 XL 8mm Proximity Probe

The Bently Nevada 330101-00-40-10-02-05 is a 3300 XL 8 mm proximity probe with 3/8-24 UNF thread, without armor. 4.0 inch case length, 1.0 metre total length with ClickLoc connector. Weight is 323 g/m (11.4 oz).

Product Information

Manufacturer Bently Nevada
Product Number 330101-00-40-10-02-05
Product Type 3300 XL 8 mm Probe
Thread Type 3/8-24 UNF
Armor Without Armor
Unthreaded Length 0.0 in
Overall Case Length 4.0 in
Total Length 1.0 metre (3.3 feet)
Connector Type Miniature Coaxial ClickLoc with Standard Cable
Agency Approvals CSA, ATEX, IECEx
Weight 323 g/m (11.4 oz)
Origin U.S.A.
Certificate Certificate of Origin (COO) Available

Model Breakdown

330101 3300 XL 8 mm Probe, 3/8-24 UNF, No Armor
00 0.0 in Unthreaded Length
40 4.0 in Overall Case Length
10 1.0 metre Total Length (3.3 ft)
02 ClickLoc Connector, Standard Cable
05 CSA, ATEX, IECEx Approvals

Technical Specifications

Linear Range 2 mm (80 mils) from 0.25 to 2.3 mm (10 to 90 mils)
Recommended Gap (Radial Vibration) -9 Vdc (1.27 mm / 50 mils)
Incremental Scale Factor (1m System) 7.87 V/mm (200 mV/mil) ±5%
Nominal DC Resistance 7.59 ± 0.50 Ω
Extension Cable Capacitance 69.9 pF/m (21.3 pF/ft) typical
Pull Strength 330 N (75 lbf)
DSL (1m System) < ±0.025 mm (±1 mil) at 0°C to +45°C

Temperature and Environment

Operating Temperature (Standard) -52°C to +177°C (-62°F to +350°F)
Probe Tip Material Polyphenylene Sulfide (PPS)
Probe Case Material AISI 303 or 304 Stainless Steel
Seal Material Viton O-Ring
Relative Humidity <3% ASF change at 93% humidity (IEC 68-2-3)

Features

  • 3300 XL 8 mm proximity probe
  • 3/8-24 UNF thread without armor
  • 4.0 inch overall case length
  • 1.0 metre total length with ClickLoc connector
  • CSA, ATEX, and IECEx approvals
  • Patented TipLoc molding for robust tip-to-body bond
  • CableLoc design with 330 N (75 lbf) pull strength
  • PPS probe tip for rugged coil encapsulation
  • Lightweight at 323 g/m (11.4 oz)
  • Certificate of Origin available

Applications

  • Radial vibration monitoring
  • Thrust position measurement
  • Eccentricity monitoring
  • Turbine supervisory systems
  • Compressor condition monitoring

FAQs

Q1: What is the case length and total length?
A1: 4.0 inch overall case length with 1.0 metre (3.3 feet) total length.

Q2: What approvals does this probe hold?
A2: CSA, ATEX, and IECEx for comprehensive safety compliance.

Q3: What is the weight and operating temperature range?
A3: 323 g/m (11.4 oz) with operating range -52°C to +177°C.
