ABB 3HAC057547-003 Servo Motor 3kW 14Nm IE3 Foot Mounted

Skladda bar (15 sany), ibermek üçin taýýar

  • Manufacturer: ABB

  • Product No.: 3HAC057547-003

  • Product Type: Servo Motor

  • Product Origin: Sweden

  • Payment:T/T, Western Union

  • Weight: 15000g

  • Shipping port: Xiamen

  • Warranty: 12 months

30 günlük yzyna gaýtaryş syýasaty · 12 aýlyk kepillik
  • Çalt eltip berme
  • 24/7 goldaw
  • Hil üpjünçiligi

Düşündiriş

ABB 3HAC057547-003 Std Foundry+ Servo Motor

The ABB 3HAC057547-003 is a 3kW servo motor designed for foundry and heavy industrial applications. Delivering 14Nm torque with IE3 efficiency, this foot-mounted motor includes a pinion for direct drive integration. Weighing 15 kg (33 lbs), it offers robust performance in demanding environments such as robotic manipulators, conveyor systems, and material handling equipment.

Product Overview

Parameter Value
Product ID 3HAC057547-003
ABB Type Designation Std / Foundry+ 3810W / 14Nm
Catalog Description Motor incl pinion
Customs Tariff Number 85015220
Part Type New
WEEE Category Product Not in WEEE Scope

Dimensions & Ratings

Parameter Value
Product Net Weight 15 kg (33 lbs)
Gross Weight 15 kg (33 lbs)
Product Net Depth / Length 318.5 mm (12.54 in)
Product Net Height 130 mm (5.12 in)
Product Net Width 130 mm (5.12 in)
Power Rating 3 kW (3810W)
Efficiency Class IE3
Mounting Type Foot Mounted

Installation & Field Application Guide

  • Mount the motor on a rigid foundation using the foot mounting holes. Ensure proper alignment with driven equipment to avoid shaft stress.
  • Use flexible couplings to connect the pinion to the driven shaft. Maintain a maximum angular misalignment of 0.5° and parallel misalignment of 0.1 mm.
  • Provide adequate ventilation around the motor. Ambient temperature should not exceed 40°C for continuous duty operation.
  • Connect the motor cables per ABB wiring diagrams. Use properly sized conductors for 3kW at the rated voltage.

Why Choose the 3HAC057547-003

  • IE3 efficiency delivers significant energy savings compared to IE2 motors.
  • Foundry+ design provides enhanced protection against dust, moisture, and thermal shock.
  • Integrated pinion enables direct drive coupling, eliminating additional gearbox components.
  • Foot mounted design simplifies installation and alignment in existing machinery.

Field Engineer FAQs

Q1: What voltage and frequency does this motor support?

A1: The 3HAC057547-003 is designed for 400V AC, 50/60 Hz operation. Verify your supply voltage matches the motor nameplate before connection.

Q2: What is the service factor of this motor?

A2: The motor has a service factor of 1.15, allowing intermittent overloads up to 15% above rated power for short durations.

Q3: How do I verify proper shaft alignment after installation?

A3: Use dial indicators or laser alignment tools. Parallel misalignment should be ≤ 0.05 mm, and angular misalignment ≤ 0.5°. Re-check alignment after thermal stabilization.
