ABB 1SAP240000R0001 DI524 32-Channel Digital Input Module 24VDC

Skladda bar (14 sany), ibermek üçin taýýar

  • Manufacturer: ABB

  • Product No.: 1SAP240000R0001

  • Product Type: Digital Input Module

  • Product Origin: SE

  • Payment:T/T, Western Union

  • Weight: 500g

  • Shipping port: Xiamen

  • Warranty: 12 months

30 günlük yzyna gaýtaryş syýasaty · 12 aýlyk kepillik
  • Çalt eltip berme
  • 24/7 goldaw
  • Hil üpjünçiligi

Düşündiriş

ABB 1SAP240000R0001 DI524 32-Channel Digital Input Module

The ABB 1SAP240000R0001 (DI524) is a 32-channel digital input module for ABB automation systems. Each channel accepts 24 V DC signals with 5 mA typical input current per channel. The module supports shielded cable runs up to 1000 meters and unshielded up to 600 meters. With a wide operating voltage range of -3 V to +30 V, it provides reliable signal acquisition for distributed I/O applications.

Technical Specifications

Parameter Value
Manufacturer ABB
Model Number 1SAP240000R0001
Series DI524
Input Channels 32 (1-wire)
Rated Input Voltage 24 V DC
Input Current per Channel 5 mA (typical @ 24 V DC)
Voltage Ripple Limit 5% maximum
Signal Voltage (0) -3 V to +5 V
Signal Voltage (Undefined) +5 V to +15 V
Signal Voltage (1) +15 V to +30 V
Operating Voltage Range -3 V to +30 V
Max Cable Length (Shielded) 1000 m (3280 ft)
Max Cable Length (Unshielded) 600 m (1968 ft)

Model Number Breakdown

  • 1SAP – ABB I/O Module Series
  • 240000 – Product Configuration Code
  • R0001 – Revision and Variant
  • DI524 – Digital Input 32 Channel, 24V DC

Installation & Field Application Guide

  • Install the module in the designated I/O slot. Ensure the backplane connector aligns properly.
  • Wire field devices to the 32 input terminals using 1-wire connection per channel. Use 24 V DC power supply.
  • For runs exceeding 600 meters, use shielded cables and ground the shield at the module end only.
  • Verify signal voltages fall within the defined ranges for proper digital state detection.

Why Choose the DI524

  • 32 input channels provide cost-effective high-density digital input acquisition.
  • Wide operating voltage range (-3 V to +30 V) handles diverse field device signals.
  • Long cable support (1000m shielded) enables remote field device placement.
  • Clear voltage threshold definitions ensure reliable signal state detection.

Field Engineer FAQs

Q1: What is the power consumption of the DI524 module?

A1: The module consumes approximately 160 mA from the backplane at 5 V DC (0.8 W) plus 5 mA per active input channel.

Q2: Can I mix different signal voltage levels on the same module?

A2: Yes, each channel independently detects signal levels between -3 V and +30 V. All channels must share the same common ground.

Q3: What happens if a channel receives voltage below -3 V?

A3: Input voltage below -3 V may damage the input circuit. Install current-limiting resistors or zener clamps for protection.
