  • 330104-00-09-10-11-05
  • 330104-00-09-10-11-05-1
  • 330104-00-09-10-11-05-2
1 3

330104-00-09-10-11-05

330104-00-09-10-11-05 Bently Nevada | M10x1 Probe

Skladda bar (25 sany), ibermek üçin taýýar

  • Manufacturer: Bently Nevada

  • Product No.: 330104-00-09-10-11-05

  • Product Type: Proximity Probe

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 330g

  • Shipping port: Xiamen

  • Warranty: 12 months

30 günlük yzyna gaýtaryş syýasaty · 12 aýlyk kepillik
  • Çalt eltip berme
  • 24/7 goldaw
  • Hil üpjünçiligi

Düşündiriş

Bently Nevada 330104-00-09-10-11-05 Proximity Probe

Product Overview

The Bently Nevada 330104-00-09-10-11-05 is a 3300 XL series 8 mm proximity probe with FluidLoc technology. It features M10×1 armored thread, IP68 fluid resistance, and a 500+ bend cycle rating. The probe withstands 100g peak shock (6ms duration) and delivers calibrated resistance of 7.59 Ω ±0.5 Ω. Weight is 0.33 kg.

Specifications

Parameter Value
Brand Bently Nevada
Model 330104-00-09-10-11-05
Series 3300 XL 8 mm Proximity Probe
Thread Design M10×1 Armored Thread
Case Length 9 mm Compact
Cable Type FluidLoc, 3-Layer Armored Shielding
Connector ClickLoc+ with Protector
Calibrated Resistance 7.59 Ω ±0.5 Ω
Cable Flexibility 500+ Bend Cycles
Fluid Resistance IP68 with FluidLoc Cable
Shock Survival 100g Peak (6 ms Duration)
Signal Integrity < 0.5% Variance @ 50 Hz EMI
Pressure Seal 4.2 MPa Burst Resistance
Connection Life 1000+ Mating Cycles
Probe Tip Material PPS, 180 °C Continuous
Seal Material Viton, -20 °C to +205 °C
Axial Positioning Accuracy ±0.1 mm
Weight 0.33 kg

Model Breakdown

Option Description
00 Zero Unthreaded Length
09 9 mm Compact Case Length
10 1.0 m Cable Length
11 ClickLoc+ Protector & FluidLoc Cable
05 Triple Industrial Certifications

Key Features

  • FluidLoc technology with IP68 fluid resistance
  • M10×1 armored thread for mechanical protection
  • 500+ bend cycle cable flexibility rating
  • Withstands 100g peak shock (6 ms duration)
  • Calibrated resistance 7.59 Ω ±0.5 Ω
  • 3-layer armored shielding for signal integrity
  • Signal variance under 0.5% at 50 Hz EMI
  • 4.2 MPa burst resistance pressure seal
  • 1000+ mating cycle connection life
  • PPS tip with 180 °C continuous thermal stability
  • Viton seal rated -20 °C to +205 °C
  • ±0.1 mm axial positioning accuracy

Installation Notes

Install the probe with M10×1 armored threading. The FluidLoc cable provides IP68 fluid resistance, preventing oil and liquid leakage through the cable interior. The 4.2 MPa burst-resistant pressure seal suits high-pressure applications. Maintain cable bend cycles within the 500+ rating for extended service life. The ClickLoc+ connector with protector supports 1000+ mating cycles. The Viton seal operates from -20 °C to +205 °C. Achieve ±0.1 mm axial positioning accuracy for precise measurements.

FAQs

Q1: What is the fluid resistance rating of this probe?

A1: IP68 with FluidLoc cable technology.

Q2: What is the shock survival rating?

A2: 100g peak for 6 ms duration.

Q3: What is the calibrated resistance value?

A3: 7.59 Ω ±0.5 Ω.

Product Resources

📄 Download PDF
🏷️ Tags: 3300 XL 8 mm Probe Proximity Probe
