330101-00-19-10-02-CN

330101-00-19-10-02-CN Bently Nevada 8mm Proximity Probe

Diňe 5 sany galdy

  • Manufacturer: Bently Nevada

  • Product No.: 330101-00-19-10-02-CN

  • Product Type: Proximity Probe

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 323g

  • Shipping port: Xiamen

  • Warranty: 12 months

30 günlük yzyna gaýtaryş syýasaty · 12 aýlyk kepillik
  • Çalt eltip berme
  • 24/7 goldaw
  • Hil üpjünçiligi

Düşündiriş

Bently Nevada 330101-00-19-10-02-CN 3300 XL 8mm Probe

The Bently Nevada 330101-00-19-10-02-CN is a 3300 XL 8 mm proximity probe with 3/8-24 UNF thread, without armor. Featuring Country Specific Approval (CN), it delivers reliable vibration monitoring with patented TipLoc and CableLoc designs for enhanced durability.

Model Number Breakdown

330101-00-19-10-02-CN

  • 330101 – 3300 XL 8 mm Probe, 3/8-24 UNF thread, without armor
  • 00 – Unthreaded Length: 0.0 in
  • 19 – Overall Case Length: 1.9 in
  • 10 – Total Length: 1.0 meter (3.3 feet)
  • 02 – Miniature coaxial ClickLoc connector, standard cable
  • CN – Country Specific Approval

Product Identification

  • Manufacturer: Bently Nevada
  • Product Number: 330101-00-19-10-02-CN
  • Type: 3300 XL 8 mm Probe
  • Thread: 3/8-24 UNF
  • Armor: Without armor
  • Origin: Made in U.S.A.
  • Approval: Country Specific Approval (CN)
  • COO: Certificate of Origin available upon request

Technical Specifications

Parameter Value
Weight 323 g/m (0.17 kg for 1.0m probe)
Unthreaded Length 0.0 in
Overall Case Length 1.9 in
Total Length 1.0 meter (3.3 feet)
Linear Range 2 mm (80 mils)
Recommended Gap -9 Vdc (~1.27 mm / 50 mils)
Scale Factor (1m System) 7.87 V/mm (200 mV/mil) ±5%
Probe Tip Material Polyphenylene Sulfide (PPS)
Probe Case Material AISI 303/304 Stainless Steel
Probe DC Resistance (1.0m) 7.59 ± 0.50 Ω
Extension Cable Capacitance 69.9 pF/m (21.3 pF/ft) typical
Field Wiring Max Length 305 m (1,000 ft)
Operating Temperature (Standard) -52°C to +177°C
Storage Temperature (Standard) -52°C to +177°C
Pull Strength 330 N (75 lbf)

Design Features

  • TipLoc Technology: Patented molding method provides robust bond between probe tip and body.
  • CableLoc Design: 330 N (75 lbf) pull strength secures probe cable and tip.
  • Thicker Encapsulation: PPS plastic tip encapsulation improves probe ruggedness.
  • Larger Diameter: Stronger, more robust case for physical abuse resistance.
  • Country Specific Approval: CN approval for regional compliance.

Installation

  • Set radial vibration gap to -9 Vdc (~1.27 mm / 50 mils).
  • Use 3-conductor shielded triad cable for field wiring (16-24 AWG).
  • Maximum field wiring length: 305 m (1,000 ft).
  • Do not expose probe below -34°C (-30°F) to prevent pressure seal failure.
  • Probe designed for differential pressure sealing with Viton O-ring.

Technical FAQs

Q1: What is the scale factor for this probe?
A1: 7.87 V/mm (200 mV/mil) ±5% for 1m system.

Q2: What is the recommended gap setting?
A2: -9 Vdc, approximately 1.27 mm (50 mils) from target.

Q3: What is the operating temperature range?
A3: -52°C to +177°C (-62°F to +350°F).
