1769-IM12

1769-IM12 Allen-Bradley CompactLogix AC Input Module 12 Points

Skladda bar (12 sany), ibermek üçin taýýar

  • Manufacturer: Allen-Bradley

  • Product No.: 1769-IM12

  • Product Type: AC Input Module

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 900g

  • Shipping port: Xiamen

  • Warranty: 12 months

30 günlük yzyna gaýtaryş syýasaty · 12 aýlyk kepillik
  • Çalt eltip berme
  • 24/7 goldaw
  • Hil üpjünçiligi

Düşündiriş

Allen-Bradley 1769-IM12 12 Channel 240V AC Input Module

Product Overview

Allen-Bradley 1769-IM12 is a 12 point AC input module for CompactLogix systems. It accepts 200 240V AC inputs with operational range of 159 264V AC at 47 63Hz. Features 20ms response time and 3.65W power dissipation. Designed for high voltage machine control, motor starter monitoring, HVAC, and power distribution applications.

Technical Specifications

Parameter Value
Brand Allen-Bradley
Model 1769-IM12
Inputs 12 AC
Nominal Voltage 200 240V AC
Operational Range 159 264V AC
Frequency 47 63Hz
Response Time 20ms ON / 20ms OFF
Operating Current 100 mA
Inrush Current 12 mA
Power Dissipation 3.65 W
Isolation 132V AC (tested at 1836V AC)
Power Supply Distance 8 modules
Replacement Terminal Block 1769-RTBN18
Wire Size 22 14 AWG
Operating Temperature 40°C to +85°C
Shock Resistance 30G
Vibration Resistance 5G
Humidity 95% non condensing
Altitude 2000m
Enclosure Open style
Weight 0.9 kg (2 lbs)

Compatibility

CompactLogix 5370 controllers. Studio 5000 and RSLogix 5000 software. 1769 series I/O expansion. Mount on DIN rail or panel. Single slot width.

Installation

Mount on DIN rail or panel. Use 22 14 AWG solid or stranded copper wire. Requires 1769 RTBN18 terminal block. Maintain proper clearance for heat dissipation. Open style enclosure for thermal management.

Applications

High voltage machine control. Motor starter monitoring. HVAC system inputs. Industrial lighting controls. Power distribution monitoring.

FAQ

Q1: What is the input voltage range for 1769-IM12?
A1: Nominal input is 200 240V AC with operational range of 159 264V AC at 47 63Hz frequency.

Q2: What is the response time?
A2: The module provides 20ms turn ON and 20ms turn OFF response time, suitable for industrial AC input applications.

Q3: Which controllers are compatible?
A3: This module works with CompactLogix 5370 controllers and supports Studio 5000 and RSLogix 5000 programming software.
