170ENT11002 Schneider TCP/IP Adapter 100BASE-TX Modicon

Skladda bar (12 sany), ibermek üçin taýýar

  • Manufacturer: Schneider

  • Product No.: 170ENT11002

  • Product Type: Adapter Module

  • Product Origin: FR

  • Payment:T/T, Western Union

  • Weight: 70g

  • Shipping port: Xiamen

  • Warranty: 12 months

30 günlük yzyna gaýtaryş syýasaty · 12 aýlyk kepillik
  • Çalt eltip berme
  • 24/7 goldaw
  • Hil üpjünçiligi

Düşündiriş

Schneider Electric 170ENT11002 Modicon Momentum Ethernet Adapter

The Schneider Electric 170ENT11002 is a Modicon Momentum Ethernet TCP/IP communication adapter featuring a 100BASE-TX port. Supporting master/slave and peer-to-peer access methods, this adapter provides robust network connectivity for industrial automation systems. Operating at 10 Mbps, it supports star and multi-drop topologies with up to 32 devices per segment. Weighing 0.07 kg (0.15 lbs), it operates from 0°C to 60°C with IP20 protection.

Technical Specifications

Parameter Value
Manufacturer Schneider Electric
Part Number 170ENT11002
Product Line Modicon Momentum
Product Type Ethernet TCP/IP Communication Adapter
Ethernet Port 100BASE-TX (10BASE-T)
Baud Rate 10 Mbps
Access Methods Master/Slave, Peer-to-Peer (P2P)
Network Topology Star, Multi-drop
Max Devices per Segment 32
Control Parameter CRC-32
Protection Class IP20
Connector RJ45
Operating Temperature 0°C to 60°C (32°F to 140°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Operating Altitude < 5,000 m (16,404 ft)
Net Weight 0.07 kg (0.15 lbs)
Country of Origin France (FR)
GTIN 3595862065054

Installation & Field Application Guide

  • Mount the adapter in a controlled environment with ambient temperature between 0°C and 60°C.
  • Connect using RJ45 connector with shielded twisted pair cable.
  • Configure IP parameters using BOOTP server or assign IP address manually.
  • For distances exceeding 1000 meters, install a repeater between segments.

Why Choose the 170ENT11002

  • Supports both star and multi-drop network topologies for flexible system design.
  • Peer-to-peer and master/slave access methods enable versatile communication.
  • CRC-32 control parameter ensures data integrity.
  • Compact design with IP20 protection suitable for control cabinet installation.

Field Engineer FAQs

Q1: What is the maximum number of devices per segment?

A1: The adapter supports up to 32 devices per segment in a multi-drop configuration.

Q2: What is the maximum cable distance between devices?

A2: Maximum distance is less than 1000 meters without a repeater. With a repeater, distances can exceed 1000 meters.

Q3: What configuration method does the adapter use for IP assignment?

A3: The adapter can be configured using a BOOTP server to assign IP parameters, or the IP address can be user-assigned.
