Product Overview

The Allen-Bradley 22B-D017H204 is a PowerFlex 40 adjustable frequency drive from Rockwell Automation. It delivers 10HP of motor control with 17A output current at 480V AC (3-phase). This VFD features sensorless vector control, Autotune, and a built-in brake IGBT for dynamic braking applications.

Core Functionality

The 22B-D017H204 controls speed and torque of 3-phase induction motors. It supports 150% overload acceleration and includes integral RS-485 communications for PC programming. The "copycat" function enables quick parameter cloning across multiple drives. Sensorless vector control and Autotune adapt to motor characteristics for optimal performance.

Technical Specifications

Installation Guide

Mount the 22B-D017H204 on a flat, non-combustible surface with adequate clearance for airflow. Use appropriately sized input and output conductors. Connect 3-phase 480V AC power to the input terminals. Set control parameters via the integral keypad or RS-485 from a PC. Install external brake resistors as required for dynamic braking applications.

Engineering Advantages

This drive delivers sensorless vector control for precise speed and torque regulation. The built-in brake IGBT eliminates external braking modules for most applications. RS-485 communication supports PC programming and network integration. The "copycat" function simplifies fleet parameter management. At 2.59 kg, the compact design reduces panel space requirements.

Technical FAQs

Q1: Supported motor control modes?
A1: Sensorless vector control and Autotune for motor adaptation. Supports 150% overload acceleration.

Q2: Communication options?
A2: Integral RS-485 supports standard 03 and 06 RTU commands. Programs via PC with Master RTU pairing.

Q3: Enclosure rating and mounting?
A3: IP20 / NEMA/UL Type Open with Plate Drive enclosure. Dimensions: 284x155x108mm. Weighs 2.59 kg (5.7 lbs).
