Yokogawa VI702 Vnet/IP Interface Card

The Yokogawa VI702 is a high-speed network interface card for industrial control systems. This card provides communication between PCI Express and Vnet/IP networks.

Technical Specifications

• Brand & Model: Yokogawa VI702
• Product Type: Vnet/IP Interface Card
• Communication Speed: 1 Gbps Full Duplex
• Power Supply: 3.3V ±9%
• Current Consumption: Maximum 2.5A
• Weight: Approximately 0.18 kg

Network & Connection

• Cable Type: CAT5e (Enhanced Category 5), UTP
• Connector: Standard RJ45 connector
• Transmission: Compliant with 1000BASE-T
• Maximum Distance: 100 meters to Layer 2 switch

Hardware Compatibility

• Replacement For: V1701 Vnet/IP Interface Card
• PCI Express: Compliant with PCIe CEM Specification 1.0a x1
• Installation: Fits PCI Express slots (x1 to x16)
• Not Compatible: Does not fit standard PCI slots

Installation Guidelines

• Install in available PCI Express x1 to x16 slot
• Connect using CAT5e Ethernet cable to network
• Ensure proper 3.3V power supply to the card
• Monitor status lamps for operational feedback

Frequently Asked Questions

• What does this card replace? It replaces the V1701 interface card.
• What network speed does it support? High-speed 1 Gbps communication.
• What type of cable is required? Standard CAT5e Ethernet cable.
