Siemens 6ES7214-1BD23-0XB0 Compact CPU

Siemens 6ES7214-1BD23-0XB0 S7-200 CPU 224

The 6ES7214-1BD23-0XB0 is a SIMATIC S7-200 compact CPU module. This unit combines a power supply, processor, and I/O in one device. It is designed for AC-powered control systems using relay outputs.

Core Technical Specifications

• Brand & Model: Siemens 6ES7214-1BD23-0XB0 (CPU 224)
• Power Supply: 120/230V AC (47-63 Hz)
• Digital Inputs: 14 channels, 24V DC (sink/source)
• Digital Outputs: 10 channels, Relay (2A @ 230V AC/30V DC)
• Program Memory: 12 KB
• Data Memory: 8 KB
• Integrated Functions: 6 counters (up to 30 kHz), 4 alarm inputs
• Expansion: Up to 7 modules, supports PROFIBUS DP

Physical Data & Features

• Dimensions: 120.5 mm x 80 mm x 62 mm (W x H x D)
• Weight: Approximately 410 grams
• Protection Rating: IP20
• Operating Temperature: 0°C to 55°C (horizontal)
• Communication: Integrated MPI/PPI interface (19.2 - 187.5 kbit/s)
• Backup: Battery backup for data retention (approx. 100 hours)
• Programming: Supports LAD, FBD, STL in STEP 7-Micro/WIN.

Frequently Asked Questions

• Q: What type of load can the relay outputs control?
  A: They can switch AC/DC loads up to 2A, such as contactors, solenoid valves, and indicator lamps.
• Q: How is this CPU powered?
  A> It uses a standard 120V or 230V AC line voltage, making it suitable for panel installations without a separate DC power supply.
• Q: Can it connect to a network?
  A: Yes, via its built-in PPI/MPI port. It can also be the master of a PROFIBUS DP network with an additional EM 277 module.
