Schneider - 140DDO84300 Modicon Quantum Output Module

Schneider Electric 140DDO84300 Discrete Output Module

The Schneider Electric 140DDO84300 is a Modicon Quantum discrete output module. It provides 16 output channels for industrial control applications. This module supports a wide 10-60V DC output voltage range.

Technical Specifications

• Brand & Model: Schneider Electric 140DDO84300
• Platform: Modicon Quantum Automation System
• Module Type: DC Discrete Output Module
• Output Channels: 16 discrete outputs
• Output Voltage: 10-60V DC (10.2-72V range)
• Current Rating: 2A per point with 8A fuses per group
• Total Current: 12A maximum per module
• Channel Groups: 2 groups of 8 outputs
• Logic Type: Positive logic (source)
• Response Time: ≤1ms for state changes
• Protection: Internal 8A fuse protection per group
• Isolation: 2500Vrms between channels and bus
• Power Dissipation: 1W + (1V × total load current)
• Weight: 0.45 kg (0.99 lb)
• Operating Temperature: 0°C to 60°C (32°F to 140°F)

Key Features

• Supports wide output voltage range from 10-60V DC
• Provides 16 high-current output points at 2A each
• Includes internal 8A fuse protection for each group
• Features comprehensive LED status indicators
• Uses positive logic for source-type output control
• Organized in 2 manageable groups of 8 outputs
• High isolation rating for enhanced safety
• Suitable for various industrial voltage requirements

Installation & Operation

• Install in Modicon Quantum baseplate or rack
• Ensure DC power supply matches 10-60V requirements
• Connect field devices to appropriate output terminals
• Monitor LED indicators for module and channel status
• Configure through control programming software
• Replace fuses only with specified 8A ratings
• Package includes the 140DDO84300 module unit
• Shipping available via FedEx, UPS, or DHL

FAQ

Q: What is the voltage range for this output module?

A: The 140DDO84300 supports a wide range from 10-60V DC for flexible application use.

Q: How are the outputs protected on this module?

A: Each group of 8 outputs has internal 8A fuse protection on the Schneider Electric 140DDO84300.

Q: What is the maximum current per output point?

A: Each output point can handle up to 2A continuous current with proper fuse protection.
