330905-05-10-10-01-00

Probe | Bently Nevada | 330905-05-10-10-01-00

In stock (24 units), ready to be shipped

  • Manufacturer: Bently Nevada

  • Product No.: 330905-05-10-10-01-00

  • Product Type: Proximity Probe

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 90g

  • Shipping port: Xiamen

  • Warranty: 12 months

30-Day Return Policy · 12-Month Warranty
  • Fast Delivery
  • 24/7 Support
  • Quality Assurance

Description

Bently Nevada 330905-05-10-10-01-00 3300 NSv Proximity Probe

The Bently Nevada 330905-05-10-10-01-00 is a high-precision 3300 NSv series eddy current proximity probe designed for critical machinery vibration and shaft position monitoring. Engineered with an M10x1 threaded AISI 304 stainless steel body, a polyphenylene sulfide (PPS) tip for superior chemical resistance, and a lightweight 1.0-meter 75Ω coaxial cable weighing approximately 0.09 kg, this non-armored transducer delivers accurate linear displacement measurements over a 1.5 mm range across extreme operating temperatures from -52°C to +177°C.

Technical Specifications

Brand / Manufacturer Bently Nevada (Baker Hughes)
Complete Part Number 330905-05-10-10-01-00
Product Family / Model 3300 NSv Proximity Transducer System
Case Thread & Unthreaded Length M10x1 Thread | 50 mm Unthreaded Length (-05)
Overall Case Length 100 mm (-10)
Total Probe Length & Cable Type 1.0 Meter / 39 in (-10) | 75Ω FEP Coaxial (Without Armor)
Estimated Net Weight Approx. 0.09 kg (0.20 lbs)
Connector Type Miniature Coaxial ClickLoc with Connector Protector (-01)
Linear Measurement Range 1.5 mm / 60 mils (0.25 to 1.75 mm gap window)
Incremental Scale Factor (ISF) 7.87 V/mm (200 mV/mil) +12.5% / -20%
Frequency Response Range 0 to 10 kHz (+0, -3 dB typical)
Probe Resistance (RPROBE) 4.2 ± 0.5 Ω (Center to Outer Conductor)
Materials (Tip / Case) Tip: Polyphenylene Sulfide (PPS) | Case: AISI 304 Stainless Steel
Agency Hazardous Area Approvals Not Required (-00)
Operating & Storage Temperature -52°C to +177°C (-62°F to +351°F)

Quick Installation Guide

  • Mount the M10x1 body into the machine housing (max 15 mm thread engagement, 7.5 N·m max case torque).
  • Set the target gap to 1.0 mm (40 mils) with a target diameter of at least 8.9 mm.
  • Route the 1.0 m FEP coaxial cable maintaining a minimum bend radius of 25.4 mm (1.0 in).
  • Hand-tighten the ClickLoc connector (0.56 N·m max) and slip the protector over the connection.

Technical FAQs

Q1: Why use a PPS tip material?
A1: It provides superior chemical resistance in harsh process compressor environments.

Q2: Is it compatible with 3300 RAM systems?
A2: Yes, it is fully mechanically and electrically interchangeable with 3300 RAM hardware.

Q3: What is the recommended probe gap setting?
A3: The recommended installation gap is 1.0 mm (40 mils) from the target shaft.
