PM862K02

PM862K02 ABB AC800M Processor 3BSE081636R1

In stock (13 units), ready to be shipped

  • Manufacturer: ABB

  • Product No.: PM862K02

  • Product Type: Redundant Processor Unit

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 1500g

  • Shipping port: Xiamen

  • Warranty: 12 months

30-Day Return Policy · 12-Month Warranty
  • Fast Delivery
  • 24/7 Support
  • Quality Assurance

Description

ABB PM862K02 Redundant Processor Module

The PM862K02 from ABB (3BSE081636R1) is a high-performance redundant processor module for AC800M controllers. Built with the MPC866 processor at 67MHz, it delivers reliable and fault-tolerant control for demanding industrial applications.

Core Specifications

  • Article Number: 3BSE081636R1 (PM862K02)
  • Processor Type: MPC866
  • Clock Frequency: 67 MHz
  • Total Memory: 32 MB
  • RAM Available for Application: 23.521 MB
  • Flash Memory for Storage: Yes (4 MB for firmware)

Redundancy & Performance

  • Redundancy: Yes
  • Switch Over Time in Redundant Configuration: Max 10 ms
  • Cycle Time per Application Programs: Down to 1 ms
  • High Integrity: No

Software & Task Configuration

  • Number of Applications per Controller: 32
  • Number of Programs per Application: 64
  • Number of Diagrams per Application: 128
  • Number of Tasks per Controller: 32
  • Number of Different Cycle Times: 32

Electrical Specifications

  • Power Supply: 24 V DC (19.2-30 V DC)
  • Power Consumption (typ/max): 210 / 360 mA
  • Power Dissipation: 5.1 W (8.6 W max)
  • Redundant Power Supply Status Input: Yes
  • Built-in Back-up Battery: Lithium, 3.6V

Communication & I/O Capacity

  • Ethernet Channels: 2
  • Communication Modules on CEX Bus: 12
  • Supply Current on CEX Bus: Max 2.4 A
  • I/O Clusters on Modulebus (Non-Redundant CPU): 1 electrical + 7 optical
  • I/O Clusters on Modulebus (Redundant CPU): 7 optical
  • I/O Capacity on Modulebus: Max 96 (single) or 84 (redundant) I/O modules
  • Modulebus Scan Rate: 0-100 ms (actual time depending on I/O modules)
  • Supply Current on Electrical Modulebus (24V): Max 1.0 A
  • Supply Current on 5V Modulebus: Max 1.5 A

Clock Synchronization & Event Handling

  • Clock Synchronization: 1 ms between AC800M controllers by CNCP protocol
  • Event Queue in Controller per OPC Client: Up to 3000 events
  • AC800M Transmission Speed to OPC Server: 36-86 events/sec, 113-143 data messages/sec

Shipping via FedEx, UPS, or DHL.

FAQs

  • What is the processor type in PM862K02?
    The PM862K02 uses the MPC866 processor running at 67MHz.
  • Does this module support redundancy?
    Yes, the PM862K02 is designed for redundant configurations with max 10ms switchover time.
  • What is the maximum I/O capacity?
    It supports up to 96 I/O modules in single configuration or 84 in redundant configuration.
