Honeywell TC-ODK161 Digital Output Module | 16-Channel

Honeywell TC-ODK161 Digital Output Module

The Honeywell TC-ODK161 Rev G0 is a high-performance 16-channel AC digital output module designed for industrial automation. This reliable module provides precise control for AC loads in demanding environments with exceptional accuracy and stability.

Product Identification

• Manufacturer: Honeywell
• Model Number: TC-ODK161
• Product Type: AC Digital Output Module
• Channels: 16 isolated outputs

Output Specifications

• Output Type: 16-channel AC digital
• Voltage Range: 90-264V AC wide range
• Nominal Voltage: 120-240V AC systems
• Accuracy: ±1% of full scale
• Isolation: Channel-to-channel isolated

Performance Characteristics

• Operating Temperature: -20°C to +70°C
• Response Time: Fast switching capability
• Reliability: Industrial grade components
• Design: Compact space-saving form

Electrical Requirements

• Power Supply: 24V DC input required
• Load Capacity: AC switching compatible
• Protection: Overload and surge protection
• Isolation: High voltage isolation

Physical Specifications

• Mounting: Standard DIN rail
• Connections: 16-pin terminal connectors
• Enclosure: Industrial grade housing
• Design: Compact panel space saving

System Compatibility

• Primary System: Honeywell Experion PKS
• Integration: Direct Experion compatibility
• PLC Systems: Most major brands supported
• Communication: Standard industrial protocols

Installation Requirements

• Mounting: DIN rail installation
• Wiring: Included diagrams provided
• Power: 24V DC supply needed
• Configuration: System integration ready

Certifications & Warranty

• UL certified for safety
• CE marked compliance
• RoHS environmental compliant
• 1-Year Manufacturer Warranty

Package Contents

• Honeywell TC-ODK161 Module
• 16-pin terminal connectors
• Installation manual
• Wiring diagrams

Application Examples

• Industrial Control Systems: The Honeywell TC-ODK161 provides reliable AC output control for motor starters, solenoid valves, and industrial lighting in factory automation, HVAC systems, and process control applications with its wide voltage range and high accuracy.

Frequently Asked Questions

• What voltage range does it support?
  90-264V AC wide operating range.
• How many output channels are available?
  16 isolated AC digital output channels.
• What systems is it compatible with?
  Honeywell Experion PKS and most PLC systems.

Documentation Download

Download Detailed Product Specifications PDF
