Honeywell MC-TDID72 Digital Input FTA Module 32-Ch

Honeywell MC-TDID72 Digital Input 24 Vdc FTA

The Honeywell MC-TDID72 provides reliable 24 Vdc digital input processing. This FTA module ensures accurate signal acquisition in industrial environments.

Core Specifications

• Model: MC-TDID72
• Input Channels: 32 Channels
• Input Voltage: 24 Vdc (±10%)
• Voltage Drop: Maximum 2 Vdc per channel

Operational Features

• Electrical Isolation: 2500 Vdc reinforced isolation
• Input Impedance: 1 kΩ per channel

Performance Metrics

• Error Detection Rate: Less than 0.1%
• Temperature Coefficient: ±0.02% per °C

Environmental Conditions

• Humidity Range: 0% to 100% RH, non-condensing
• Vibration Resistance: Tolerates up to 2 g @ 10-150 Hz

Additional Features

• Compliance Standards: Exceeds IEC 61131-2 and UL 508
• Networking Capability: Integrates with Honeywell control systems

Frequently Asked Questions

What does reinforced isolation of 2500 Vdc provide?

This isolation protects your control system from voltage spikes. It prevents damage to sensitive electronics from power surges.

How many input devices can I connect to this module?

The MC-TDID72 supports up to 32 separate input devices. Each channel handles 24 Vdc signals independently.

Is this module suitable for harsh industrial environments?

Yes, the module tolerates 100% humidity and significant vibration. It operates reliably in demanding factory conditions.
