Honeywell FC-PDB-0824 | 8-Channel 24V Distribution Module

In stock (14 units), ready to be shipped

  • Manufacturer: Honeywell

  • Product No.: FC-PDB-0824

  • Product Type: Distribution Module

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 480g

  • Shipping port: Xiamen

  • Warranty: 12 months

30-Day Return Policy · 12-Month Warranty
  • Fast Delivery
  • 24/7 Support
  • Quality Assurance

Description

Honeywell FC-PDB-0824 Power Distribution Module

The Honeywell FC-PDB-0824 distributes 24V power across 8 fused channels. It features 2A slow-blow fuses per channel for reliable field power distribution.

Core Specifications

  • Brand: Honeywell
  • Model: FC-PDB-0824
  • Channels: 8 fused outputs
  • Voltage: 24V DC nominal
  • Fuse Rating: 2A slow-acting per channel
  • Fuse Size: 5 x 20 mm

Approvals & Compliance

  • CE: Compliant
  • UL: Pending
  • TUV: Pending
  • CSA: Pending
  • RoHS: Compliant

Connector Specifications

  • Input Connector: 2-pole keyed header
  • Input Make/Type: Weidmuller BVZ 7.62/02F SW
  • Input Keys: Weidmuller KO BV/SV7.62
  • Field Connector: 2-pole socket block
  • Field Make/Type: Weidmuller BL 5.08/2 SN OR

Mechanical Dimensions

  • Module Dimensions: 94 x 109 x 71 mm (L x W x H)
  • DIN Rail Compatibility: TS32 / TS35 x 7.5
  • Rail Length Used: 95 mm (3.74 in)
  • Housing Material: Flame-retardant plastic
  • Protection Rating: IP20

Electrical Characteristics

  • Input Voltage Range: 19.2 - 30V DC
  • Max Total Current: 16A (8 x 2A)
  • Voltage Drop per Channel: <0.1V at 2A
  • Isolation: No isolation between channels
  • Fuse Type: 5x20mm slow-blow (user replaceable)

Environmental

  • Operating Temperature: -20 to +60°C
  • Storage Temperature: -40 to +85°C
  • Humidity: 5-95% non-condensing
  • Vibration Resistance: 2g, 10-150 Hz
  • Flammability Rating: UL94 V-0

Package Contents

  • One FC-PDB-0824 distribution module
  • Input connector (Weidmuller BVZ 7.62/02F SW)
  • Input keys (Weidmuller KO BV/SV7.62) - 2 pcs
  • 8 x field connectors (Weidmuller BL 5.08/2 SN OR)
  • Fuses not included (user supplied)
  • Product documentation
  • Shipping: FedEx, UPS, DHL

Installation Guide

  • Mount on TS32 or TS35 DIN rail
  • Snap module onto 95mm rail section
  • Install input keys into header
  • Mate input connector with power supply
  • Insert 5x20mm 2A slow-blow fuses
  • Connect field wiring to orange socket blocks
  • Label channels per application

FAQ

What fuses are required?
5x20mm slow-blow type, 2A maximum rating per channel.

Can I use fast-acting fuses?
No, use slow-acting only to prevent nuisance tripping.

Are field connectors included?
Yes, 8 orange Weidmuller socket blocks included.

🏷️ Tags: Distribution Module
  • Orange
  • Black
  • DC-powered
  • Compact
  • Modular

Scalar (V/f)

Vector

AC-powered
  • Confirm the exact model, part number, and specifications before ordering.
  • Ensure compatibility with your current machinery or control systems.
  • Reach out via sale@etowonauto.com or +8617859788089 for technical assistance.
  • Review delivery options, lead times, and shipping requirements.
  • Follow manufacturer instructions and best practices during installation.

In-stock items are typically dispatched the same business day. For products not currently in stock, dispatch times may vary based on availability. International shipping is available, and shipping costs are calculated according to destination, weight, and carrier selection.

Returns are accepted within 30 days of receipt, provided items are unused and in original condition. Return shipping costs are the responsibility of the customer. Please contact us before returning any item to receive return authorization.

For more details, please review our Shipping & Return Policy.
