Honeywell CC-PCNT02 C300 Module Controller

Honeywell CC-PCNT02 C300 Module Controller

Experience advanced process control with the upgraded CC-PCNT02 module. This high-performance controller delivers reliable operation in demanding industrial environments with enhanced processing capabilities.

Core Technical Data

• Brand: Honeywell
• Model: CC-PCNT02
• Measurement Range: Programmable for various process variables
• Accuracy: ±0.1% of calibrated span
• Output Signal: Ethernet with redundant communication
• Operating Temperature: -30°C to 60°C (-22°F to 140°F)
• Storage Temperature: -40°C to 85°C (-40°F to 185°F)
• Power Requirements: 24V DC ±10%, 0.4A maximum
• Physical Dimensions: 89mm x 140mm x 38mm (3.5" x 5.5" x 1.5")
• Unit Weight: 0.3 kg

Installation Guide

• Mount in standard C300 mounting racks
• Ensure proper power supply (24V DC ±10%)
• Connect Ethernet cables for communication
• Verify grounding for optimal performance
• Allow adequate ventilation around the unit

Compatibility Information

• Direct upgrade replacement for CC-PCNT01
• Fully compatible with C300 system architecture
• Works with existing Honeywell control systems
• Supports legacy I/O modules and components

Certifications & Compliance

• CE certified for European market
• UL listed for safety standards
• ATEX certified for explosive atmospheres
• RoHS compliant for hazardous substances
• IEC 61131-2 industrial standard compliant

Warranty Terms

• 1-year limited warranty from date of purchase
• Covers manufacturing defects and component failures
• Includes technical support during warranty period
• Warranty validation requires proof of purchase

Frequently Asked Questions

• What are the main improvements in CC-PCNT02 compared to CC-PCNT01?
  The CC-PCNT02 features enhanced processing power, improved communication capabilities, and better integration with modern control systems.
• Can I use this controller with my existing C300 system?
  Yes, the CC-PCNT02 is designed for seamless integration with current C300 architecture and existing installations.
• What is the warranty coverage for this product?
  Honeywell provides a comprehensive 1-year warranty covering manufacturing defects and component failures.
