CC-PAIH51

Honeywell CC-PAIH51 Analog Input HART Module | 16-Channel

In stock (23 units), ready to be shipped

  • Manufacturer: Honeywell

  • Product No.: CC-PAIH51

  • Product Type: Analog Input Module

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 500g

  • Shipping port: Xiamen

  • Warranty: 12 months

30-Day Return Policy · 12-Month Warranty
  • Fast Delivery
  • 24/7 Support
  • Quality Assurance

Description

Honeywell CC-PAIH51 Analog Input Module with HART

The Honeywell CC-PAIH51 is a 16-channel analog input module. It supports HART protocol for smart device communication. This module handles 4-20mA current signals with high precision. It's designed for reliable process monitoring in industrial control systems.

Key Specifications

  • Brand: Honeywell
  • Model: CC-PAIH51 - High-Level Analog Input with HART
  • Input Type: 4-20mA Current (2-wire or self-powered)
  • Channels: 16 single-ended inputs
  • Resolution: 16 bits A/D converter
  • Accuracy: ±0.075% FS (@23.5°±2°C), ±0.15% FS (0-60°C)
  • Scan Rate: 50 ms per channel
  • CMRR: 70 dB (dc to 60 Hz)
  • Input Impedance: 200 Ω

Performance Features

  • Signal Range: 4-20mA only (through 200Ω resistor)
  • Noise Rejection: 19 dB NMRR at 60 Hz, -60 dB crosstalk
  • Filter: Single-pole RC, -3dB @ 6.5 Hz
  • Max Input: ±30V normal mode protection
  • CMV Range: -6 to +5V peak
  • IOTA Models: CC-TAIX51 (6" non-redundant), CC-TAIX61 (12" redundant)

Installation Notes

  • Installs into compatible Honeywell IOTA carriers
  • Supports HART digital communication over 4-20mA signal
  • Terminal blocks and carriers sold separately
  • Follow plant wiring standards for noise reduction
  • Configure via system software for scaling and addressing

Shipping Details

  • Includes: 1x CC-PAIH51 analog input module
  • Carrier and accessories sold separately
  • Shipped via FedEx, UPS, or DHL
  • Secure packaging ensures safe delivery

Frequently Asked Questions (FAQ)

What is the HART protocol advantage?

  • The HART protocol enables digital communication with smart devices. It allows configuration and diagnostics without interrupting the 4-20mA signal on the CC-PAIH51.

Can it accept voltage signals?

  • No. The CC-PAIH51 is designed for 4-20mA current signals only. Use different Honeywell modules for voltage inputs.

What does single-ended input mean?

  • All 16 channels share a common ground reference. This is standard for 4-20mA loops but requires proper grounding to minimize noise.
