Honeywell 16-Channel High Voltage Digital Input Module CC-TDI220

The Honeywell CC-TDI220 is a robust 16-channel digital input module for high-voltage applications. Designed for the Experion Series-C DCS, it reliably monitors 120V AC or DC field signals from devices like proximity switches. Its wide operating temperature range makes it suitable for demanding industrial environments.

Core Specifications

• Brand & Model: Honeywell CC-TDI220
• Product Type: High Voltage Digital Input Module
• Series: Experion Series-C DCS
• Input Channels: 16 Channels
• Input Voltage Range: 90-132 V AC RMS / 100-138 V DC
• Nominal Voltage: 120V AC/DC
• Operating Temperature: -40°C to +70°C
• Mounting: DIN Rail or Panel Mount

Packaging & Shipping

• One Honeywell CC-TDI220 digital input module.
• Factory packaging ensuring protection.
• Shipped via FedEx, UPS, or DHL.

FAQ

• What types of devices can connect to this module?
  It is designed for 120V AC or DC discrete signals from devices like proximity switches, limit switches, selector switches, and relay contacts.
• Can it be used with lower voltage signals (e.g., 24V DC)?
  No, it is specifically designed for high-voltage inputs. For lower voltages, a different module from the series should be used.
• Is this module hot-swappable?
  Within the Experion Series-C system architecture, I/O modules typically support hot-swapping, but refer to system documentation for specific procedures and cautions.
