369B1842G5005

GE MAO50 369B1842G5005 Analog Output Module 8CH

In stock (21 units), ready to be shipped

  • Manufacturer: General Electric

  • Product No.: 369B1842G5005

  • Product Type: Analog Output Module

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 500g

  • Shipping port: Xiamen

  • Warranty: 12 months

30-Day Return Policy · 12-Month Warranty
  • Fast Delivery
  • 24/7 Support
  • Quality Assurance

Description

GE MAO50 369B1842G5005 Analog Output Module

The GE MAO50 369B1842G5005 is an 8-channel analog output module designed for industrial control systems. Featuring 12-bit D/A conversion per channel, it delivers 0-20mA (4-20mA) or 0-5V outputs with 0.1% accuracy, providing precise analog signal generation for field devices.

Product Identification

  • Manufacturer: GE Nexus (General Electric)
  • Part Number: MAO50 / 369B1842G5005
  • Product Type: Analog Output Module
  • Number of Channels: 8
  • Certification: CE Certified (with system)

Technical Specifications

Parameter Value
Weight Approx. 0.5 kg
Dimensions (H×W×D) 209 × 129.5 × 51 mm
Number of Outputs 8
Output Range 0-20mA / 4-20mA, 0-5V (selected channels)
Load Capacity (Current) Max 1000Ω
Load Capacity (Voltage) Min 500kΩ
Accuracy Max 0.1%
D/A Conversion 12-bit, individual per channel
Power Supply 24V DC (±10%), dual redundant
Power Consumption < 6.5W
Channel-to-Channel Isolation 250V AC
Channel-to-Ground Isolation 500V AC
Channel-to-System Isolation 1500V AC
CMRR > 120dB
Processor High-performance 32-bit embedded
Communication Redundant high-speed serial bus, 1Mbps, DB-9 (female)
Terminal Connection Single-row Euro-style, removable (2.5mm²)
Operating Temperature 0°C to 60°C
Humidity 10% to 90% non-condensing

LED Indicators

  • Module Run Status
  • Communication Status
  • Fault Alarm

Standards and Compliance

  • CFR 47 FCC Part 15: 2009
  • ANSI C63.4-2003
  • EN 61326-1: 2006
  • CISPR 11: 2007
  • IEC 61000-4-2/3/4/5/6/8/11
  • CE Certified (with system)

Installation

  • Mount via screw installation.
  • Connect dual redundant 24V DC power supply.
  • Use DB-9 connector for communication.
  • Removable Euro-style terminal for field wiring (2.5mm²).
  • Ensure operating temperature within 0°C to 60°C range.

Technical FAQs

Q1: How many analog outputs does the MAO50 have?
A1: 8 analog output channels.

Q2: What output ranges are supported?
A2: 0-20mA / 4-20mA, and 0-5V on selected channels.

Q3: What is the accuracy of the outputs?
A3: Maximum 0.1% with 12-bit resolution per channel.
