IC693CHS392

GE Fanuc IC693CHS392 10-Slot Expansion Baseplate PLC

In stock (15 units), ready to be shipped

  • Manufacturer: General Electric

  • Product No.: IC693CHS392

  • Product Type: Expansion Baseplate

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 1500g

  • Shipping port: Xiamen

  • Warranty: 12 months

30-Day Return Policy · 12-Month Warranty
  • Fast Delivery
  • 24/7 Support
  • Quality Assurance

Description

GE Fanuc IC693CHS392: 10-Slot Expansion Baseplate

The GE Fanuc IC693CHS392 is a 10-slot expansion baseplate for Series 90-30 PLC systems. This baseplate connects to CPU baseplates via I/O bus cables up to 50 feet (15 meters) total length. Engineers choose the IC693CHS392 to expand I/O capacity when CPU memory and processing demands increase.

Key Specifications

  • Part Number: IC693CHS392
  • Brand: GE Fanuc
  • Product Type: 10-Slot Expansion Baseplate
  • Slots: 10 I/O or option module slots
  • Connector: 25-pin female D-type I/O Bus Expansion
  • Max Cable Length: 50 feet (15 meters) total
  • Rack Selection: DIP switch configurable
  • Weight: 1.5 kg (3.3 lbs)

Compatibility & Limitations

  • Must connect to a system with a CPU (PLC or PC interface card)
  • Max 4 baseplates with CPU 331, 340, 341
  • Max 7 baseplates with CPU 350 and higher
  • Cannot stand alone without CPU connection

Supported Modules

  • Accepts all standard I/O modules
  • Supports most option modules
  • Does NOT support PCM, ADC, BEM330, CMM modules (CPU baseplate only)
  • Same physical size and power supplies as Remote baseplates

Key Features

  • 10-slot design for system expansion
  • DIP switch for rack number selection
  • Common ground connection required
  • 25-pin female D-type connector for daisy-chain
  • Identical form factor to Remote baseplates

Package Contents

  • 1x GE Fanuc IC693CHS392 10-slot expansion baseplate
  • Factory sealed anti-static packaging
  • Original GE Fanuc box

Shipping Information

  • FedEx, UPS, DHL Express worldwide
  • Same-day dispatch for in-stock items
  • Tracking provided immediately

FAQs

Q: Weight of GE Fanuc IC693CHS392?

A: 1.5 kg (3.3 lbs).

Q: Maximum cable length between baseplates?

A: 50 feet (15 meters) total interconnecting cable length.

Q: Which CPUs are compatible with this baseplate?

A: CPUs 331, 340, 341 (max 4) and CPUs 350+ (max 7).
