IC693CBL332

GE Fanuc IC693CBL332 2M Cable 24-Pin 90-Degree Series 90-30

In stock (12 units), ready to be shipped

  • Manufacturer: General Electric

  • Product No.: IC693CBL332

  • Product Type: Connector Cable

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 150g

  • Shipping port: Xiamen

  • Warranty: 12 months

30-Day Return Policy · 12-Month Warranty
  • Fast Delivery
  • 24/7 Support
  • Quality Assurance

Description

GE Fanuc IC693CBL332 24-Pin 90-Degree Cable for Series 90-30

The GE Fanuc IC693CBL332 is a 2-meter right-side connector cable designed for the Series 90-30 PLC system. Featuring two 24-pin 90-degree connectors with tighteners, this cable provides reliable terminal block interface connectivity for IC694 series PLCs. Built with high-grade copper conductors and industrial-grade PVC jacket, it ensures durable performance in factory automation environments. Weighing approximately 0.15 kg (0.33 lbs), it offers a lightweight and flexible solution for cabinet wiring.

Technical Specifications

Parameter Value
Brand GE Fanuc
Series Series 90-30
Model Number IC693CBL332
Description Right-Side Connector Cable with 90-Degree Connectors
Cable Length 2 Meters (6.56 Feet)
Weight 0.15 kg (0.33 lbs)
Connector Type Two 24-Pin 90-Degree Connectors with Tighteners
Conductor Current Rating 1.6 Amps Continuous
Cable Orientation Right-Side
Cable Shielding Unshielded
Compatible PLCs GE Fanuc IC694 Series
Connection Type Terminal Block Interface
Bending Radius Minimum 50 mm (1.97 Inches)
Operating Temperature -20°C to +60°C (-4°F to +140°F)
Conductor Material High-Grade Copper Core
Outer Jacket Material Industrial-Grade PVC
Voltage Rating Up to 300V
Environmental Standards RoHS and CE Compliant
Certifications Conforms to Global Industrial Standards

Model Number Breakdown

  • IC693 – GE Fanuc Series 90-30 PLC Compatible
  • CBL – Connector Cable
  • 332 – Specific Right-Side 24-Pin 90-Degree Cable Variant

Installation & Field Application Guide

  • Before installation, ensure zero voltage and complete power disconnection from the PLC system.
  • Route the cable with a minimum bending radius of 50 mm to prevent conductor stress and insulation damage.
  • Secure connectors using the built-in tighteners. Torque to 0.5 Nm maximum to avoid thread stripping.
  • Avoid running the cable parallel to high-voltage power lines. Maintain a minimum separation of 300 mm to reduce EMI interference.

Why Choose the IC693CBL332

  • 90-degree connector design allows installation in tight cabinet spaces with limited clearance.
  • High-grade copper core ensures low signal loss and reliable data transmission.
  • Industrial-grade PVC jacket provides resistance to oils, chemicals, and abrasion.
  • RoHS and CE compliance meets global environmental and safety standards.

Field Engineer FAQs

Q1: Is this cable compatible with IC693 Series PLCs?

A1: Yes, the IC693CBL332 is fully compatible with GE Fanuc Series 90-30 PLCs, specifically the IC693 and IC694 series.

Q2: What is the maximum current each conductor can carry?

A2: Each conductor is rated for 1.6 Amps continuous. For higher current loads, use multiple conductors in parallel.

Q3: Can this cable be used in high-vibration environments?

A3: Yes, the tighteners securely lock the connectors in place. For extreme vibration, additional cable clamps are recommended every 300 mm.
