GE Fanuc Field Control IC670TBM001 Terminal Block DIN Mount

GE Fanuc IC670TBM001 Technical Overview

The GE Fanuc IC670TBM001 is an auxiliary terminal block designed for the Field Control system architecture. Weighing approximately 0.04 kg (0.09 lbs), this barrier-style terminal strip provides 9 dedicated termination points for expanding wiring capacity across analog and high-density discrete I/O modules. Housed in a compact form factor for direct DIN rail mounting, each terminal accepts 1 or 2 AWG #14 gauge wires (2.1 mm² cross-section), offering essential ground, return, common, and shield connections within industrial control panels.

Part Number Breakdown

• IC670: GE Fanuc Field Control I/O System Product Family
• TBM: Terminal Block Module Functional Designation
• 001: 9-Terminal Barrier-Style Auxiliary Terminal Strip Configuration (Qty. 2 Pack)

Technical Specifications Table

Key Features & System Integration

The IC670TBM001 auxiliary terminal strip provides internal bused connections that simplify wiring by eliminating external jumper wires. Weighing just 0.04 kg, it mounts directly to the side of standard Field Control I/O terminal blocks on standard DIN rails. It is particularly effective for multi-wire field devices—such as 3-wire or 4-wire transmitters—by providing organized termination tie points for field cable shields, common return lines, and module chassis grounding connections.

Frequently Asked Questions (FAQs)

Q1: Are the 9 terminals on the IC670TBM001 isolated or connected?
A1: The terminals are electrically bused together internally to function as a common distribution strip.

Q2: How is the auxiliary terminal block installed?
A2: It attaches to the right-side mounting ears of the main I/O terminal block on the DIN rail.

Q3: What wire size does the IC670TBM001 accommodate?
A3: Each barrier terminal accepts up to 1 or 2 wires of AWG #14 (2.1 mm²) gauge.
