Bently Nevada 3500/05-01-03-00-00-01 14-Slot Rack Module

In stock (15 units), ready to be shipped

  • Manufacturer: Bently Nevada

  • Product No.: 3500/05-01-03-00-00-01

  • Product Type: System Rack

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 4900g

  • Shipping port: Xiamen

  • Warranty: 12 months

30-Day Return Policy · 12-Month Warranty
  • Fast Delivery
  • 24/7 Support
  • Quality Assurance

Description

Bently Nevada 3500/05-01-03-00-00-01 14-Slot Rack Chassis

The 3500/05-01-03-00-00-01 is a 14-slot rack chassis designed for the Bently Nevada 3500 monitoring system. It provides a rugged mounting platform for monitoring modules in critical turbomachinery applications such as compressors, turbines, and pumps. This rack ensures reliable operation in harsh industrial environments.

Ordering Code Configuration

The 3500/05-01-03-00-00-01 part number follows this structure: 3500/05-AA-BB-CC-DD-EE

  • AA – Rack Size: 01 = 19-inch (standard)
  • BB – Mounting Options: 03 = Bulkhead mount (not available in Mini-Rack)
  • CC – Agency Approval: 00 = None
  • DD – Reserved Options: 00 = None
  • EE – European Compliance: 01 = CE

Technical Specifications

Parameter Value
Product Number 3500/05-01-03-00-00-01
Rack Size 19-inch (standard)
Number of Module Slots 14
Mounting Options Bulkhead mount (not available in Mini-Rack)
Agency Approval None
European Compliance CE
Dimensions (L x W x H) 48.26 x 34.92 x 26.59 cm (19.0 x 13.75 x 10.47 in)
Shipping Weight 4.5 kg (9.9 lbs)
Operating Temperature -20°C to +60°C (-4°F to +140°F)
Power Supply 120/240 VAC or 24 VDC

Installation & Field Application Guide

  • Mount the rack in a clean, dry location with adequate ventilation. Allow 50mm clearance on all sides for airflow.
  • Use the bulkhead mounting option for secure installation on panel or cabinet walls.
  • Ensure proper grounding using the rack's ground lug with 4 mm² (AWG 11) stranded wire.
  • Power supply input should be protected with a 10A circuit breaker per local electrical codes.

Why Choose the 3500/05 Rack

  • Accommodates up to 14 monitoring modules for comprehensive machinery protection.
  • CE compliance ensures adherence to European safety and EMC standards.
  • Bulkhead mounting provides stable installation in high-vibration environments.
  • Compatible with all 3500 series modules including TDI, vibration, and temperature monitors.

Field Engineer FAQs

Q1: What is the maximum power draw for a fully loaded 14-slot rack?

A1: A fully populated rack draws approximately 150W at 24VDC. Use a power supply rated for 200W minimum to allow headroom.

Q2: Can I mount this rack in a standard 19-inch server cabinet?

A2: Yes, the 19-inch rack size fits standard server cabinets. Use the included mounting brackets for secure rail installation.

Q3: What is the recommended maintenance schedule for the rack?

A3: Inspect all module connections annually. Clean dust filters (if installed) every 6 months. Check ground continuity annually.
