330104-00-05-05-02-05

Bently Nevada 330104-00-05-05-02-05 3300 XL 8mm Proximity Probe

In stock (23 units), ready to be shipped

  • Manufacturer: Bently Nevada

  • Product No.: 330104-00-05-05-02-05

  • Product Type: Proximity Probe

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 323g

  • Shipping port: Xiamen

  • Warranty: 12 months

30-Day Return Policy · 12-Month Warranty
  • Fast Delivery
  • 24/7 Support
  • Quality Assurance

Description

Bently Nevada 3300 XL 8mm Proximity Transducer Probe (330104-00-05-05-02-05)

The Bently Nevada 330104-00-05-05-02-05 is a premium 3300 XL 8mm reverse mount proximity probe engineered for continuous critical machinery vibration and axial position monitoring. Designed with a 0.5-meter overall length, ClickLoc connector, and Viton® O-ring sealing, this probe weighs approximately 0.323 kg (0.71 lbs) and delivers precise non-contact displacement measurement against rotating shaft targets in severe industrial environments.

Key Performance Advantages

Delivers high linear measuring accuracy for dynamic vibration and static displacement tracking on turbomachinery. Built with hazardous area global safety approvals (CSA, ATEX, IECEx) and robust ClickLoc miniature coaxial connectors, ensuring secure, vibration-resistant connectivity in high-duty applications.

Part Number Breakdown (330104-00-05-05-02-05)

Unthreaded Length Option (-00) 00 = 0.0 in (0 mm) Unthreaded Length
Overall Case Length Option (-05) 05 = 50 mm Overall Case Length
Total Length Option (-05) 05 = 0.5 meter (20 inches) Total Length
Connector Option (-02) 02 = Miniature ClickLoc coaxial connector, standard lead
Agency Approval Option (-05) 05 = Multiple Approvals (CSA, ATEX, IECEx)

Technical Specifications

Manufacturer & Series Bently Nevada (3300 XL 8mm Series)
Part Number 330104-00-05-05-02-05
Supply Voltage & Linear Range -17.5 Vdc to -26 Vdc / 2.0 mm (80 mils) Linear Range
Probe Resistance & Weight 7.45 Ω ± 0.5 Ω / Approx. 0.323 kg (0.71 lbs)
Target Material & Sealing AISI 4140 Steel Target / Viton® O-Ring Seal
Operating Temperature Range -51°C to +177°C (-60°F to +350°F) Body/Tip Range
Hazardous Area Certifications CSA Class I Div 1 / ATEX & IECEx Zone 0/1 Intrinsic Safety

Installation & Operation Guidelines

  • Gap Setting: Set target gap to approximately 1.27 mm (50 mils) to achieve a nominal -10 Vdc bias output baseline.
  • System Matching: Connect to a matching 3300 XL Proximitor and extension lead to maintain system length calibration (5m or 9m total length).
  • Connector Care: Hand-tighten ClickLoc connectors firmly; avoid using pliers or excessive torque to prevent coaxial pin damage.

Frequently Asked Questions

Q1: Has EMC filter?
A1: N/A (Eddy current proximity transducer).

Q2: Key feature vs PF523?
A2: Non-contact shaft displacement probe & ATEX/IECEx ratings.

Q3: Drives 3-phase motors?
A3: No, measures vibration and shaft gap position.
