330101-00-55-10-02-05

Bently Nevada 3300 XL Probe 330101-00-55-10-02-05 1.0m

In stock (15 units), ready to be shipped

  • Manufacturer: Bently Nevada

  • Product No.: 330101-00-55-10-02-05

  • Product Type: Proximity Probe

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 131g

  • Shipping port: Xiamen

  • Warranty: 12 months

30-Day Return Policy · 12-Month Warranty
  • Fast Delivery
  • 24/7 Support
  • Quality Assurance

Description

Bently Nevada 330101-00-55-10-02-05 3300 XL Proximity Probe

Bently Nevada 330101-00-55-10-02-05 is a 3300 XL 8mm proximity probe with 3/8-24 UNF thread, without armor. Features 5.5 inch overall case length and 1.0 meter total length. Includes miniature coaxial ClickLoc connector with standard cable and CSA, ATEX, IECEx approvals. Weight: 0.131 kg (0.29 lbs).

Technical Specifications

Parameter Specification
Manufacturer Bently Nevada
Model 330101-00-55-10-02-05
Product Type 3300 XL 8mm Proximity Probe
Country of Origin Made in U.S.A.
Thread Type 3/8-24 UNF, without armor
Unthreaded Length 0 inches
Overall Case Length 5.5 inches
Total Length 1.0 meter (3.3 feet)
Connector Type Miniature coaxial ClickLoc, standard cable
Agency Approval CSA, ATEX, IECEx
Electrical Resistance 1000 Ohm
Response Time 5 ms
Dynamic Range 0-50 mm
Operating Voltage 10-30V DC
Operating Humidity 0-95% RH
Weight 0.131 kg (0.29 lbs)

Configuration Breakdown

Code Description
330101 3300 XL 8mm Probe, 3/8-24 UNF thread, without armor
-00 Unthreaded Length: 0 inches
-55 Overall Case Length: 5.5 inches
-10 Total Length: 1.0 meter (3.3 feet)
-02 Connector: Miniature coaxial ClickLoc, standard cable
-05 Agency Approval: CSA, ATEX, IECEx

Key Features

  • 5.5 inch overall case length for deep mounting applications
  • 8mm PPS probe tip with thick encapsulation for durability
  • CSA, ATEX, and IECEx approvals for hazardous areas
  • 1000 Ohm electrical resistance
  • Fast 5 ms response time
  • Wide dynamic range 0-50 mm
  • Operating voltage 10-30V DC
  • Made in U.S.A.

Installation Guidelines (Field Engineer Notes)

Mounting: Thread into 3/8-24 UNF hole. Recommended torque is 5.1 N·m (45 in·lb). Maximum torque 7.3 N·m (65 in·lb).

Gap Setting: Recommended gap for radial vibration is -9 Vdc (approximately 1.27 mm / 50 mils).

Field Wiring: Use 3-conductor shielded triad cable (16-24 AWG). Maximum length is 305 meters (1,000 feet) between Proximitor Sensor and monitor.

Temperature: Standard operating range -52°C to +177°C (-62°F to +350°F). Exposing below -34°C (-30°F) may cause premature pressure seal failure.

FAQs

Q1. What is the overall case length of this probe?
A1. The probe has a 5.5 inch overall case length, suitable for deep mounting applications.

Q2. What approvals does this probe hold?
A2. The probe holds CSA, ATEX, and IECEx approvals for hazardous area operation.

Q3. What is the response time of this probe?
A3. The probe provides a fast 5 ms response time for dynamic measurement applications.
