X20RT8001

B&R X20RT8001 reACTION Technology Module

Only 10 units left

  • Manufacturer: B&R

  • Product No.: X20RT8001

  • Product Type: I/O Module

  • Product Origin: AT

  • Payment:T/T, Western Union

  • Weight: 500g

  • Shipping port: Xiamen

  • Warranty: 12 months

30-Day Return Policy · 12-Month Warranty
  • Fast Delivery
  • 24/7 Support
  • Quality Assurance

Description

X20RT8001 reACTION Technology Module

B&R X20RT8001 delivers 1 µs response times. Four high-speed digital inputs. Four configurable mixed channels. ABR incremental encoder input. Blackout mode support.

Technical Specifications

  • Digital Inputs: 4 standard + 4 mixed, 24 VDC sink, filter <3 µs
  • Digital Outputs: 4 mixed push-pull, 100/530 mA configurable, switching delay <1 µs
  • Encoder Input: 1 ABR incremental, 24 V, 333 kHz max frequency, 32-bit counter
  • Encoder Supply: 24 VDC, 600 mA, short-circuit protected
  • Response Time: 1 µs via reACTION Technology
  • Blackout Mode: Programmed logic runs during network failure
  • Isolation: Channel to bus 856 VAC (revision ≥E0)
  • Temperature: -25 to 60°C horizontal, -25 to 50°C vertical
  • Certifications: CE, UL, ATEX Zone 2, DNV, CCS, LR, KR, ABS, BV
  • Memory: 64 Mbit flash, 100,000 write cycles

Package Contents

  • 1x X20RT8001 reaction module
  • Quick start guide
  • Shipping via FedEx, UPS, DHL
  • X20TB12 terminal block and X20BM11 bus module sold separately

FAQ

Q: Can I use mixed channels as inputs?

Yes. Software configures each mixed channel as input or output.

Q: What is max output current?

530 mA per channel on revision ≥E0. Total 2.12 A max.

Q: What encoders work with X20RT8001?

24 V asymmetrical incremental encoders (A, B, R). 333 kHz max frequency.
