X20DM9324

B&R X20DM9324 Sink Input Source Output

In stock (12 units), ready to be shipped

  • Manufacturer: B&R

  • Product No.: X20DM9324

  • Product Type: I/O Module

  • Product Origin: AT

  • Payment:T/T, Western Union

  • Weight: 500g

  • Shipping port: Xiamen

  • Warranty: 12 months

30-Day Return Policy · 12-Month Warranty
  • Fast Delivery
  • 24/7 Support
  • Quality Assurance

Description

B&R X20DM9324 8DI 4DO Digital Module with 1-Wire Connections

B&R X20DM9324 provides 8 digital inputs and 4 digital outputs for 1-wire connections. Inputs use sink configuration while outputs use source configuration. Features configurable software filter and integrated output protection.

I/O Specifications

  • 8 digital inputs: Sink connections
  • 4 digital outputs: Source connections
  • 1-wire connection technology
  • Nominal voltage: 24 VDC
  • Configurable software input filter for entire module
  • Integrated output protection

Diagnostics & Status

  • B&R ID code: 0x20B9
  • Status indicators per channel for I/O function
  • Operating state and module status LEDs
  • Diagnostics via LED and software for module run/error
  • Output error status via LED and software

Power Consumption

  • Bus power: 0.21 W
  • Internal I/O power: 0.5 W
  • Additional actuator power dissipation: +0.21 W (resistive)

Package Includes

  • B&R X20DM9324 digital module unit
  • Documentation and quick start guide

Shipping

  • FedEx, UPS, DHL worldwide with tracking

FAQ

What connection type does this module use?

1-wire connections for both inputs and outputs.

Are inputs sink or source?

Inputs are sink connections. Outputs are source connections.

Can I filter input noise?

Yes. Configurable software filter applies to all inputs.
