22B-D017H204

Allen-Bradley 22B-D017H204 VFD | 10HP 480V AC

In stock (16 units), ready to be shipped

  • Manufacturer: Allen-Bradley

  • Product No.: 22B-D017H204

  • Product Type: AC Drive

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 2590g

  • Shipping port: Xiamen

  • Warranty: 12 months

30-Day Return Policy · 12-Month Warranty
  • Fast Delivery
  • 24/7 Support
  • Quality Assurance

Description

Product Overview

The Allen-Bradley 22B-D017H204 is a PowerFlex 40 adjustable frequency drive from Rockwell Automation. It delivers 10HP of motor control with 17A output current at 480V AC (3-phase). This VFD features sensorless vector control, Autotune, and a built-in brake IGBT for dynamic braking applications.

Core Functionality

The 22B-D017H204 controls speed and torque of 3-phase induction motors. It supports 150% overload acceleration and includes integral RS-485 communications for PC programming. The "copycat" function enables quick parameter cloning across multiple drives. Sensorless vector control and Autotune adapt to motor characteristics for optimal performance.

Technical Specifications

Parameter Value
Part Number 22B-D017H204
Series PowerFlex 40
Input Voltage 380-480V AC (3-phase)
Output Current 17.0 A
Horsepower 10 HP (7.5 kW)
Enclosure IP20 / NEMA/UL Type Open (Plate Drive)
Brake Built-in Brake IGBT
CE Filter Not included
Communication RS-485 (integral)
Control Type Sensorless Vector / Autotune
Overload Capability 150% acceleration
Control Voltage 24V DC (sink/source)
Dimensions (H x W x D) 284 x 155 x 108 mm (11.18 x 6.1 x 4.25 in)
Weight 2.59 kg (5.7 lbs)

Installation Guide

Mount the 22B-D017H204 on a flat, non-combustible surface with adequate clearance for airflow. Use appropriately sized input and output conductors. Connect 3-phase 480V AC power to the input terminals. Set control parameters via the integral keypad or RS-485 from a PC. Install external brake resistors as required for dynamic braking applications.

Engineering Advantages

This drive delivers sensorless vector control for precise speed and torque regulation. The built-in brake IGBT eliminates external braking modules for most applications. RS-485 communication supports PC programming and network integration. The "copycat" function simplifies fleet parameter management. At 2.59 kg, the compact design reduces panel space requirements.

Technical FAQs

Q1: Supported motor control modes?
A1: Sensorless vector control and Autotune for motor adaptation. Supports 150% overload acceleration.

Q2: Communication options?
A2: Integral RS-485 supports standard 03 and 06 RTU commands. Programs via PC with Master RTU pairing.

Q3: Enclosure rating and mounting?
A3: IP20 / NEMA/UL Type Open with Plate Drive enclosure. Dimensions: 284x155x108mm. Weighs 2.59 kg (5.7 lbs).

Product Resources

📄 Download PDF
🏷️ Tags: AC Drive

Scalar (V/f)

Vector

AC-powered
