Allen-Bradley 22B-B8P0C104 PowerFlex 40 AC Drive 3HP

Allen-Bradley 22B-B8P0C104 PowerFlex 40 AC Drive

Allen-Bradley 22B-B8P0C104 is a PowerFlex 40 adjustable frequency AC drive with 180-264V AC 3-phase input and 0-230V AC output. Delivers 8.0A output current with 3.0 HP (2.2 kW) power rating. Features IP66 NEMA Type 4X enclosure for dust-tight and water-resistant protection. Weight: 5.3 kg (11.7 lbs).

Technical Specifications

Key Features

• IP66 NEMA Type 4X enclosure for dust-tight and water-resistant protection
• 97.5% efficiency for energy savings
• 0-400 Hz output frequency range
• 3.0 HP (2.2 kW) power rating with 8.0A current
• 24V sink/source control voltage
• Wide operating temperature range -10°C to +50°C
• Adjustable frequency AC drive for motor speed control

Installation Guidelines (Field Engineer Notes)

Mounting: Ensure adequate clearance for airflow. IP66 enclosure allows outdoor installation. Use all mounting holes with M6 bolts. Torque to 8 N·m.

Power Wiring: Use 14 AWG minimum for input and output power. Torque terminals to 1.0 N·m. Connect ground to PE terminal. Verify phase sequence.

Control Wiring: Use shielded twisted pair for control signals. Connect shield to ground terminal at one end only. Maintain 50mm separation from power cables.

Temperature Derating: Derate current by 2.5% per °C above 40°C. Do not exceed 50°C ambient.

FAQs

Q1. What enclosure rating does this drive have?
A1. The drive is rated IP66 and NEMA Type 4X for dust-tight and water-resistant protection, suitable for outdoor and washdown applications.

Q2. What is the output frequency range?
A2. The drive provides 0-400 Hz output frequency range for flexible motor speed control.

Q3. Can this drive be installed outdoors?
A3. Yes. The IP66 NEMA Type 4X enclosure allows outdoor installation. Ensure proper cable entries and seals are used.
