Allen-Bradley 1794-OB32P Flex I/O High-Density Output Module

32-Channel DC Output Module

The Allen-Bradley 1794-OB32P controls multiple DC loads. This Flex I/O module offers 32 sourcing outputs with 200g weight.

Key Specifications

• Model: Allen-Bradley 1794-OB32P
• Type: Flex I/O Digital DC Output Module
• Outputs: 32 sourcing channels
• Output Current: 500 mA max per channel
• Total Current: 14.0 A max per module
• Voltage: 24 VDC nominal ON state
• Leakage Current: 0.5 mA max OFF state
• Voltage Drop: 0.5 VDC max
• Isolation: 50 V continuous
• Power Dissipation: 5.3 W @ 31.2 VDC max
• Thermal Dissipation: 18.1 BTU/hr @ 31.2 VDC max
• Flexbus Current: 80 mA @ 5 VDC
• Weight: 200 g module weight

Environmental Ratings

• Operating Temperature: 0°C to 55°C (32°F to 131°F)
• Storage Temperature: -40°C to 85°C (-40°F to 185°F)
• Vibration: 5 g @ 10 to 500 Hz
• Operating Shock: 30 g tolerance

Key Features

• 32-channel high-density output
• Sourcing output configuration
• High 500mA per channel current
• 14A total module current capacity
• Compact 200g lightweight design
• Low 0.5V voltage drop

FAQ

How many outputs does this module have?

32 sourcing digital output channels.

What is the current rating per channel?

500 mA maximum per output channel.

What is the module weight?

200 g lightweight design for easy installation.
