ABB YT204001-KA/5 YPQ201A Control Board 24V DC IP20 Module

In stock (21 units), ready to be shipped

  • Manufacturer: ABB

  • Product No.: YT204001-KA/5

  • Product Type: Control Board

  • Product Origin: Sweden

  • Payment:T/T, Western Union

  • Weight: 420g

  • Shipping port: Xiamen

  • Warranty: 12 months

30-Day Return Policy · 12-Month Warranty
  • Fast Delivery
  • 24/7 Support
  • Quality Assurance

Description

Product Overview

The YT204001-KA/5 (also designated as YPQ201A) is a high-performance control board engineered by ABB for industrial automation and processing systems. Built on a durable FR-4 flame-retardant resin substrate, this control module operates on a 24 V DC supply with a low current consumption of 0.3 A. Featuring a rapid 1 ms cycle time and an RS-485 communication interface, it delivers fast, reliable data processing. Weighing 0.42 kg with compact dimensions of 3.8 cm x 15.2 cm x 15 cm, the IP20-rated board includes intuitive green and red status LEDs for real-time diagnostic monitoring.

Core Technical Advantages

  • Rapid Processing Speed: Executes control tasks with a fast 1 ms cycle time for responsive industrial automation.
  • Robust FR-4 Build: Constructed from flame-retardant resin material to ensure long-term thermal and structural stability.
  • Diagnostic LED Status: Dual-color green and red LEDs provide instant operational and fault feedback.

Technical Specifications

Parameter Specification Details
Brand & Manufacturer ABB
Model Part Number YT204001-KA/5 (YPQ201A)
Product Designation Control Board Module
Input Voltage Rating 24 V DC
Current Consumption 0.3 A
Processing Cycle Time 1 ms
Communication Interface RS-485 Serial Interface
Diagnostic Indicators Status LEDs (Green and Red)
Board Substrate Material FR-4 (Flame Retardant Resin)
Enclosure Protection Class IP20
Operating Temperature Range -20°C to +60°C
Storage Temperature Range -40°C to +85°C
Physical Dimensions (LxWxH) 3.8 cm x 15.2 cm x 15 cm
Product Net Weight 0.42 kg (420 g)

Industrial Applications

  • Industrial Control Racks: Manages internal logic processing within ABB automation subracks.
  • Serial Communication Networks: Links field devices and controllers via RS-485 communication protocols.
  • Process Automation Systems: Executes high-speed control loops in power generation and manufacturing plants.

Wiring & Installation

  • Subrack Insertion: Slide the YT204001-KA/5 board securely into the designated enclosure slot, ensuring backplane pins align.
  • Power Supply Connection: Wire a regulated 24 V DC source to the input terminals, verifying correct polarity.
  • Communication Cabling: Connect twisted-pair shielded cables to the RS-485 interface terminals for network data exchange.

Engineering Advantages

  • Low Power Draw: Consumes only 0.3 A at 24V DC, reducing thermal load inside control cabinets.
  • Lightweight Design: Weighs only 0.42 kg to minimize mechanical stress on rack mounting guides.
  • Wide Thermal Range: Operates reliably in ambient temperatures from -20°C to +60°C.

Technical FAQs

Q1: What communication protocol does the YT204001-KA/5 board utilize?
A1: It features an industrial RS-485 serial interface for robust multi-drop data communication.

Q2: What is the processing cycle time for this control board?
A2: The module achieves a fast execution cycle time of 1 ms.

Q3: What power supply parameters are required to operate the module?
A3: The board requires a 24 V DC input voltage and draws a nominal current of 0.3 A.
