3HAW050008637-002

ABB 3HAW050008637-002 | Resolver Track M2008 2m Cable

In stock (12 units), ready to be shipped

  • Manufacturer: ABB

  • Product No.: 3HAW050008637-002

  • Product Type: Cable

  • Product Origin: Sweden

  • Payment:T/T, Western Union

  • Weight: 440g

  • Shipping port: Xiamen

  • Warranty: 12 months

30-Day Return Policy · 12-Month Warranty
  • Fast Delivery
  • 24/7 Support
  • Quality Assurance

Description

Product Overview

The ABB 3HAW050008637-002 is a 2m Resolver Track M2008 cable assembly designed for resolver feedback systems. This analog signal cable delivers reliable position and speed data in servo and motion control applications. It features a circular connector, 5V DC rated voltage, and IP67 environmental protection.

Core Functionality

This resolver cable transmits analog signals between resolver sensors and control units. The 2m length provides flexible installation options. IP67 rating ensures protection against dust and water ingress for demanding industrial environments. The cable is designed for resolver feedback systems in robotics, CNC machines, and servo drives.

Technical Specifications

Parameter Value
Part Number 3HAW050008637-002
Description 1 Resolver Track M2008 No SMB 2m
Rated Voltage 5V DC
Length 2.0 m
Connector Type Circular Connector
Signal Type Analog
Frequency Response 0 - 10 kHz
Protection Class IP67
Operating Temperature -25°C to +70°C
Weight 0.44 kg
Customs Tariff Number 85444290

Installation Guide

Connect the circular connector to the resolver sensor. Route the 2m cable to the control unit, avoiding sharp bends and excessive strain. Ensure the connector is fully seated and locked. For IP67 integrity, verify the connector seal is clean and undamaged. Keep cable away from high-voltage power cables to minimize noise interference.

Engineering Advantages

This resolver cable delivers reliable analog signal transmission with 0-10kHz frequency response. IP67 protection ensures operation in washdown and dusty environments. The 2m length provides installation flexibility. Wide temperature range (-25°C to +70°C) supports both indoor and outdoor applications. The circular connector ensures secure, vibration-resistant connections.

Technical FAQs

Q1: Signal type and frequency?
A1: Analog signal with 0-10kHz frequency response. 5V DC rated voltage.

Q2: Environmental rating?
A2: IP67 protection. Operating temperature -25°C to +70°C. Suitable for harsh industrial conditions.

Q3: Cable length?
A3: 2.0m. Weight 0.44 kg. Circular connector with locking mechanism.
