ABB 3BSE069055R1 Relay Output Module | 2A 16-Channel
Manufacturer: ABB
Product No.: 3BSE069055R1
Product Type: Digital Output Module
Product Origin: SE
Payment:T/T, Western Union
Weight: 180g
Shipping port: Xiamen
Warranty: 12 months
Share
- Fast Delivery
- 24/7 Support
- Quality Assurance
Description
ABB 3BSE069055R1 Digital Output Module Technical Specifications
The ABB DO828 provides reliable relay output control for industrial automation systems. This 16-channel module handles both AC and DC loads with individual channel isolation. It offers robust performance and comprehensive diagnostics for demanding applications.
Product Identification
- Manufacturer: ABB
- Model: DO828 Digital Output Module
- Part Number: 3BSE069055R1
- Module Type: Relay Output for S800 I/O Systems
- Certifications: CE, UL, ATEX Zone 2, DNV Marine
Electrical Specifications
- Output Channels: 16 individually isolated relays
- Voltage Rating: 250V AC / 125V DC maximum
- Current Capacity: 2A per channel continuous
- Contact Type: SPDT (Single Pole Double Throw)
- Operating Range: 5-250V AC / 5-125V DC
- Dielectric Strength: 2000V AC test voltage
- Power Dissipation: 3.5W typical
Environmental Specifications
- Operating Temperature: 0°C to +55°C
- Storage Temperature: -40°C to +70°C
- Humidity Range: 5% to 95% non-condensing
- Vibration Resistance: IEC 60068-2-6 compliant
- Shock Resistance: IEC 60068-2-27 compliant
- Pollution Degree: Level 2 classification
Physical Characteristics
- Dimensions: 119mm H × 45mm W × 102mm D
- Weight: 0.18 kg (0.4 lbs)
- Mounting: Standard DIN rail installation
- Protection Class: IP20 according to IEC 60529
- Field Wiring: 600 meters maximum cable length
Installation & Compatibility
- Compatible with S800 I/O systems
- Designed for use with TU851 mounting unit
- Keying code: ED for proper installation
- DIN rail mounting for easy installation
- Maximum ambient temperature: 55°C
