5466-355 Woodward Micro-D Differential Line Driver Interface

In stock (12 units), ready to be shipped

  • Manufacturer: Woodward

  • Product No.: 5466-355

  • Product Type: Power Supply

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 450g

  • Shipping port: Xiamen

  • Warranty: 12 months

30-Day Return Policy · 12-Month Warranty
  • Fast Delivery
  • 24/7 Support
  • Quality Assurance

Description

Woodward 5466-355 Remote Chassis Transceiver Module

The Woodward 5466-355 is a high-speed Remote Chassis Transceiver (Remote XCVR) module specifically designed for CPU 68040 control systems. Installed directly into Slot 1 of remote I/O chassis, this module interfaces with the VME bus via high-speed differential line drivers and dual 100-pin metal shell Micro-D connectors to maintain rapid, low-latency control, data, and address transmission. Weighing approximately 0.45 kg (1.00 lb), it ensures high signal integrity across complex, multi-chassis industrial control architectures.

Technical Specifications

Manufacturer & Origin Woodward (Made in USA)
Part Number / Model 5466-355
Product Type Remote Chassis Transceiver Module (Remote XCVR)
System Compatibility Woodward CPU 68040 Control Systems & VME Bus
Cable Interface Dual 100-Pin Metal Shell Micro-D Connectors
Bus & Signaling Type Parallel Interface with High-Speed Differential Line Drivers
Required Installation Slot Slot 1 in Expansion / Remote I/O Chassis
Termination Resistors Required only on the final expansion chassis in the chain
Interconnect Cabling 3 ft (0.9 m) for T-Modules | 10 ft (3 m) for Chassis Links
Approximate Net Weight 0.45 kg (1.00 lbs)

Quick Installation Guide

  • Install the 0.45 kg 5466-355 module exclusively into Slot 1 of each remote expansion chassis.
  • Ensure non-terminated modules are used for intermediate expansion racks, and reserve the terminated version strictly for the final chassis in the chain.
  • Secure 100-pin Micro-D cables between the Main Transceiver, T-Modules, and Remote XCVR units using proper strain relief and torque standards.

Technical FAQs

Q1: What CPU systems support the Woodward 5466-355 transceiver?
A1: The module is exclusively designed for use with Woodward CPU 68040 control systems.

Q2: Where must this module be installed within the expansion chassis?
A2: It is strictly required to be installed in Slot 1 of each remote I/O chassis.

Q3: How are cable lengths selected for multi-chassis interconnects?
A3: Uses 3 ft (0.9 m) cables for T-Module connections and 10 ft (3 m) cables for links between chassis setups.
