SD834

3BSC610067R1 ABB SD834 Power Supply Unit 1200g DIN Rail

In stock (19 units), ready to be shipped

  • Manufacturer: ABB

  • Product No.: SD834

  • Product Type: Power Supply

  • Product Origin: Sweden

  • Payment:T/T, Western Union

  • Weight: 1200g

  • Shipping port: Xiamen

  • Warranty: 12 months

30-Day Return Policy · 12-Month Warranty
  • Fast Delivery
  • 24/7 Support
  • Quality Assurance

Description

ABB SD834 3BSC610067R1 Power Supply Unit

Product Overview

The ABB SD834 (Article Number 3BSC610067R1) is a switch-mode power supply unit delivering 24 Vdc at 20 A (480 W). Accepting both AC and DC input (100-240 V AC, 110-150 V DC), it achieves up to 93.9% efficiency. Designed for SELV and PELV applications, the SD834 supports parallel connection for increased output power and features a floating DC-OK relay contact. Weight is 1200 g (2.6 lbs).

Specifications

Parameter Value
Brand ABB
Model SD834
Article Number 3BSC610067R1
Type Switch-Mode Power Supply
Input Voltage 100-240 V AC / 110-150 V DC
Input Voltage Range 85-276 V AC / 88-187 V DC
Mains Frequency 50-60 Hz ±6%
Rated Output Voltage 24 Vdc
Rated Output Current 20 A
Rated Output Power 480 W
Maximum Output Current 30 A (< 4 s)
Efficiency 92.4% / 93.9%
Power Factor 0.95 / 0.90
Heat Dissipation 40 / 31 W
Ripple (peak to peak) < 100 mV
Output Voltage Regulation < 10 mV / < 100 mV at max current
Holdup Time (230V, 20A) 36 ms min / 51 ms typ
Holdup Time (120V, 20A) 22 ms min / 32 ms typ
Primary Inrush Current < 13 A
Supervision Relay Floating DC-OK relay contact
Load Sharing Parallel connection supported
Maximum Ambient Temperature 55 °C
Protection Rating IP20 (IEC 60529)
Electrical Safety IEC 61131-2, UL 508, EN 50178
Hazardous Location Class 1 Div 2 (cULus)
Marine Certification ABS, BV, DNV-GL, LR
Overvoltage Category Category III (IEC/EN 60664-1)
Equipment Class Class I (with PE connection)
Dimensions (W x H x D) 82 x 124 x 127 mm
Weight 1200 g (2.6 lbs)

Key Features

  • 20 A rated output current, 30 A peak for 4 seconds
  • 480 W output power with up to 93.9% efficiency
  • AC and DC input capability for flexible installation
  • Parallel connection for increased output power
  • Floating DC-OK relay contact for supervision
  • Soft start feature prevents tripping fuses or earth-fault breakers
  • Over-current and over-voltage protection
  • SELV and PELV accepted for secondary circuits
  • Class I equipment with protective earth connection
  • Class 1 Div 2 hazardous location certified (cULus)
  • Marine certified (ABS, BV, DNV-GL, LR)
  • Over-voltage Category III for primary mains connection
  • DIN-rail mounting with simple installation
  • No external mains filter required

Installation Notes

Mount the unit on standard DIN rail with minimum spacing of 15 mm (W) and 40 mm (H) for proper airflow. Connect to 100-240 V AC or 110-150 V DC input. Ensure protective earth (PE) connection for Class I equipment. For redundant applications, use diode voting units SS823 or SS832. Recommended external fuse: 10-20 A. Observe maximum ambient temperature of 55 °C.

FAQs

Q1: What is the maximum output current of the SD834?

A1: 20 A rated continuous, with 30 A peak for less than 4 seconds.

Q2: Can multiple SD834 units be paralleled?

A2: Yes. The SD834 supports parallel connection to increase output power. For redundant configurations, use SS823 or SS832 voting units.

Q3: What certifications does this power supply carry?

A3: CE, IEC 61131-2, UL 508, EN 50178, Class 1 Div 2 (cULus), marine (ABS, BV, DNV-GL, LR), RoHS, WEEE.
