330701-00-40-10-02-00

330701-00-40-10-02-00 Bently Nevada | 11mm XL Proximity Probe

Only 10 units left

  • Manufacturer: Bently Nevada

  • Product No.: 330701-00-40-10-02-00

  • Product Type: Proximity Probe

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 150g

  • Shipping port: Xiamen

  • Warranty: 12 months

30-Day Return Policy · 12-Month Warranty
  • Fast Delivery
  • 24/7 Support
  • Quality Assurance

Description

Product Overview

The Bently Nevada 330701-00-40-10-02-00 is a 3300 XL 11mm Proximity Probe designed for non-contact vibration and position monitoring of rotating machinery. This rugged probe features a PPS tip, AISI 304 stainless steel case, and 1.0m cable with ClickLoc connector. It operates reliably from -51°C to +177°C for demanding turbine and compressor applications.

Suffix Configuration

Suffix Description
00 Unthreaded length: 0 in
40 Case length: 4.0 in
10 Cable length: 1.0 m
02 ClickLoc connector, standard cable
00 No approvals required

Technical Specifications

Parameter Value
Part Number 330701-00-40-10-02-00
Model 3300 XL 11mm Proximity Probe
Tip Material Polyphenylene Sulfide (PPS)
Case Material AISI 304 Stainless Steel
Thread Size 1/2-20 UNF
Unthreaded Length 0 in
Case Length 4.0 in
Cable Length 1.0 m (3.3 ft)
Connector Type ClickLoc Miniature Coaxial
Cable Resistance (1m) 5.9Ω ± 0.5Ω
Operating Temperature -51°C to +177°C (-60°F to +350°F)
Seal Material Viton® O-ring (5 bar max)
Case Torque (Rated) 400 in·lb
Case Torque (Recommended) 133 in·lb
Connector Torque Finger-tight to 5 in·lb
Min. Bend Radius 1 in (25.4 mm)
Weight Approx. 0.15 kg (0.33 lbs)
Country of Origin USA

Installation Guide

Thread the probe into the mounting hole with recommended torque of 133 in·lb. Engage threads up to 0.75 in maximum. Maintain minimum 1 in bend radius on cable. Connect the ClickLoc connector with finger-tight torque (5 in·lb max). For sealing applications, ensure Viton O-ring is properly seated. Verify cable resistance (5.9Ω ± 0.5Ω) and connector integrity before system start-up.

Engineering Advantages

This probe delivers reliable performance in extreme temperatures (-51°C to +177°C) with PPS tip for chemical resistance. The 304 stainless steel case and Viton seal handle harsh environments up to 5 bar. The ClickLoc connector ensures secure signal transmission. At just 0.15 kg, it minimizes mechanical loading on machinery.

Technical FAQs

Q1: What is the difference between suffix codes?
A1: 00=unthreaded 0in, 40=case length 4.0in, 10=cable 1.0m, 02=ClickLoc connector, 00=no approvals.

Q2: Temperature and pressure limits?
A2: Operating -51°C to +177°C. Viton O-ring seal rated to 5 bar. Cable bend radius minimum 1 inch.

Q3: Recommended installation torque?
A3: Case torque 133 in·lb (rated 400 in·lb max). Connector torque finger-tight to 5 in·lb.
