330103-06-10-50-02-00

330103-06-10-50-02-00 Bently Nevada 3300 XL Probe

In stock (15 units), ready to be shipped

  • Manufacturer: Bently Nevada

  • Product No.: 330103-06-10-50-02-00

  • Product Type: Proximity Probe

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 200g

  • Shipping port: Xiamen

  • Warranty: 12 months

30-Day Return Policy · 12-Month Warranty
  • Fast Delivery
  • 24/7 Support
  • Quality Assurance

Description

Product Overview

The Bently Nevada 330103-06-10-50-02-00 is a 3300 XL 8mm reverse-mount proximity probe. This eddy current sensor provides high-precision, non-contact measurement of shaft vibration and axial position. Designed for critical turbines and compressors, it ensures reliable machinery protection in extreme industrial environments.

Technical Configuration

  • -06 (Unthreaded): 60 mm section for housing penetration.
  • -10 (Case Length): 100 mm total threaded case.
  • -50 (Total Length): 5.0 Meters (16.4 ft) calibrated length.
  • -02 (Connector): ClickLoc Miniature Coaxial.
  • -00 (Agency Approval): Standard industrial version.

Technical Specifications

Feature Specification
Tip Diameter 8.0 mm
Linear Range 2.0 mm (80 mils)
Sensitivity 7.87 V/mm (200 mV/mil)
Temp Range -52°C to +177°C
Resistance ~8.73 Ω
Housing Material AISI 304 Stainless Steel

Installation Guide

  • Gap Voltage: Set the mechanical gap to achieve -9.0 VDC at the Proximitor output.
  • Mounting Torque: Maximum limit of 25 N·m (221 in·lb).
  • Cable Integrity: Maintain a minimum bend radius of 25.4 mm (1.0 in) for coaxial cables.

Engineering Advantages

The PPS polymer tip provides superior chemical resistance against synthetic oils, while the ClickLoc connector ensures a vibration-proof signal link. This probe is factory-tuned for seamless integration with Bently Nevada 3500 Monitoring Systems.

Technical FAQs

Q1: Can I use this with a 9m Proximitor?
A1: No. This 5m probe must be used with a 5m calibrated system to maintain accuracy and scale factor.

Q2: What is the benefit of the Reverse Mount (330103)?
A2: It allows for installation from inside the machine housing, ideal for restricted access points.

Q3: How do I verify if the probe is healthy?
A3: Measure resistance between the center pin and shield; it should read between 7.5 and 10 Ω.
