330101-00-52-15-02-05

330101-00-52-15-02-05 Bently Nevada | 3300 XL 8mm Probe

In stock (23 units), ready to be shipped

  • Manufacturer: Bently Nevada

  • Product No.: 330101-00-52-15-02-05

  • Product Type: Proximity Probe

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 320g

  • Shipping port: Xiamen

  • Warranty: 12 months

30-Day Return Policy · 12-Month Warranty
  • Fast Delivery
  • 24/7 Support
  • Quality Assurance

Description

Product Overview

The Bently Nevada 330101-00-52-15-02-05 is an 8 mm proximity probe from the industry-standard 3300 XL series, manufactured by Bently Nevada in the USA. Designed for non-contact vibration and position measurement on rotating machinery shafts, this probe features a 3/8-24 UNF thread with an overall case length of 5.2 inches and 0 inches of unthreaded length. Equipped with a 1.5-meter (4.9 ft) FEP insulated cable and a miniature coaxial ClickLoc connector, it delivers a precise linear range of 2 mm and an output scale factor of 8.0 V/mm. With an IP67 environmental sealing rating, severe shock/vibration resistance, and a broad operational temperature range of -35 °C to +177 °C, this probe includes hazardous area approvals from CSA, ATEX, and IECEx. The module features an estimated net weight of 0.32 kg (0.71 lbs).

Technical Specifications

Parameter Specification
Part Number / Option Code 330101-00-52-15-02-05
Manufacturer / Brand Bently Nevada
Product Series / Probe Type 3300 XL 8 mm Proximity Probe
Thread Option (-330101) 3/8-24 UNF Thread, Unarmored
Unthreaded / Case Length (-00 / -52) 0.0 in Unthreaded / 5.2 in Case Length
Total Length Option (-15) 1.5 Meters (4.9 Feet)
Connector / Cable Option (-02) Miniature Coaxial ClickLoc Connector, Standard Cable
Hazardous Area Approvals (-05) CSA, ATEX, IECEx Certified
Linear Range / Output Voltage 2 mm (80 mils) / 8.0 V/mm (200 mV/mil)
Operating Temperature Range -35 °C to +177 °C (-31 °F to +350 °F)
Environmental Sealing / Cable Material IP67 / Fluorinated Ethylene Propylene (FEP)
Product Net Weight 0.32 kg (0.71 lbs)
Country of Origin United States (USA)

Key Hardware & Operational Features

  • ClickLoc Miniature Coaxial Connector: Patented locking connector design prevents fluid ingress and accidental disconnection under severe machinery vibration.
  • Robust FEP Cable Construction: Fluoropolymer jacket offers superior resistance to chemical attack, oil degradation, and extreme temperature variations.
  • Global Explosion-Proof Certifications: Multi-agency approval (CSA, ATEX, IECEx) ensures compliance for installation in Zone 0, 1, or 2 hazardous locations.
  • IP67 Sealed Sensing Tip: Molded probe tip provides complete dust protection and water submersion resistance up to 1 meter depth.

Installation & Gap Setting Guidelines

1. Mechanical Mounting: Thread the 3/8-24 UNF probe body into the machine housing or probe bracket, taking care not to twist or pinch the attached cable.

2. Physical Gap Setting: Set the initial mechanical probe gap using a feeler gauge or by monitoring the Proximitor sensor DC output voltage to establish the linear mid-range point.

3. Cable Connection & Strain Relief: Click the ClickLoc connector securely into place with the matching extension cable and secure the lead with proper cable clamps.

Frequently Asked Questions (FAQs)

Q1: What is the cable length and connector type?
A1: 1.5 meters (4.9 ft) cable with a ClickLoc miniature coaxial connector.

Q2: What certifications are included with the -05 option?
A2: CSA, ATEX, and IECEx hazardous area approvals.

Q3: What are the linear range and sensitivity scale factors?
A3: 2 mm linear measurement range with an output sensitivity of 8.0 V/mm.
