330101-00-48-10-02-00 Bently Nevada 3300 XL Probe

Bently Nevada 330101-00-48-10-02-00 8mm Proximity Probe

The probe functions as a high-performance 8mm non-contact proximity transducer designed for continuous vibration and position monitoring in rotating machinery. Featuring a lightweight 323 g/m cable assembly, this 3300 XL series component delivers precise eddy current measurements to evaluate shaft vibration and thrust position.

Technical Specifications

Quick Installation Guide

• Set the mechanical gap distance precisely by monitoring the sensor output voltage to establish the core linear operational range.
• Support the lightweight 323 g/m cable properly along the internal machine routing to minimize mechanical strain on the connector.
• Engage the ClickLoc coaxial connector securely; do not exceed the 75 lbf pull limit during installation.

Technical FAQs

Q1: What does the 4.8-inch specification indicate?
A1: It dictates the unthreaded case length, ensuring proper mechanical reach through outer machine housings or brackets.

Q2: Does the 323 g/m cable weight affect system performance?
A2: No, the 323 g/m weight represents an optimized low-mass design that prevents excessive cable sagging while maintaining heavy-duty electrical shielding.

Q3: How resilient is this probe to extreme ambient humidity?
A3: The unit holds IEC 68-2-3 certification, resisting up to 93% relative humidity for 56 continuous days with only a 3% variance in performance.
