Schneider Electric 140AMM09000 Analog Input/Output Module

The Schneider Electric 140AMM09000 is a versatile analog I/O module for Modicon Quantum systems. This module combines 4 analog inputs and 2 analog outputs in a single unit for flexible signal processing and control.

Key Technical Specifications

• Brand: Schneider Electric
• Model: 140AMM09000
• Product Type: Analog Input/Output Module
• Analog Inputs: 4 channels with multiple ranges
• Input Types: ±20mA, ±10V, ±5V, 0-20mA, 4-20mA, 1-5V, 0-10V, 0-5V
• Analog Outputs: 2 channels of 4-20mA
• Output Resolution: 12 bits
• Update Time: 320 ms (inputs), 15 ms (outputs)

Input Performance Features

• Input Resolution: Up to 16 bits for voltage signals
• Absolute Accuracy: ±0.03% of full scale at 25°C
• Common Mode Rejection: >80 dB at 50/60 Hz
• Maximum Input: ±25 mA current, ±50 V voltage
• Input Impedance: >10 MΩ (voltage), >250 Ω (current)

Output Performance Features

• Output Accuracy: ±0.20% of full scale at 25°C
• Settling Time: 900 µs to ±0.1% of final value
• Loop Voltage: 7-30 V DC with external resistance up to 60V
• Diagnostics: Open circuit detection for both inputs and outputs
• Monotonic: ±1 LSB for both input and output circuits

Isolation & Protection

• Channel Isolation: 500V AC/750V DC between all channels
• Bus Isolation: 500V AC/750V DC between channels and bus
• I/O Isolation: 500V/750V between input and output channels
• Certifications: FM Class 1 Division 2, C-Tick, UL 508, CSA
• Operating Temperature: 0°C to 60°C (32°F to 140°F)

Module Indicators & Installation

• Status LEDs: 1 green (bus active), 1 red (external fault)
• Channel LEDs: 6 green (active), 6 red (fault) - one per channel
• Bus Current: 350 mA requirement
• Module Format: Standard Quantum rack mount
• Weight: 0.7 lb (0.3 kg)

Shipping & Packaging

• Package Includes: 1 x 140AMM09000 module
• Package Dimensions: 12.20" × 6.46" × 1.97" (31.0 × 16.4 × 5.0 cm)
• Shipping Weight: 16.3 oz (461 g)
• Shipping Options: FedEx, UPS, DHL

Frequently Asked Questions

• What I/O configuration does this module have? It provides 4 analog inputs and 2 analog outputs.
• What input signals are supported? It accepts current (±20mA, 0-20mA, 4-20mA) and voltage (±10V, ±5V, 0-10V, 0-5V, 1-5V) signals.
• What is the output signal type? Both outputs provide standard 4-20 mA current signals.
