330104-04-10-10-02-CN

330104-04-10-10-02-CN Bently Nevada 1.0m Probe

På lager (24 enheter), klar til å sendes

  • Manufacturer: Bently Nevada

  • Product No.: 330104-04-10-10-02-CN

  • Product Type: Proximity Probe

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 323g

  • Shipping port: Xiamen

  • Warranty: 12 months

30 dagers returrett · 12 måneders garanti
  • Rask levering
  • 24/7 kundestøtte
  • Kvalitetssikring

Beskrivelse

Product Overview

The Bently Nevada 330104-04-10-10-02-CN is a high-precision 3300 XL 8 mm proximity probe designed for specific mounting configurations. This model is unique for its 4 mm unthreaded length combined with a 10 mm overall case length, making it ideal for installations where the probe must pass through a bracket before being secured by its M10 x 1 threads.

Built to rigorous U.S.A. manufacturing standards, this probe includes integrated stainless steel armor for superior mechanical protection. Despite its armored construction, the system weight remains approximately 323 g/m (11.4 oz) for the cable portion. It utilizes a durable Polyphenylene sulfide (PPS) tip and a Viton® O-ring to provide a pressure-tight seal against harsh industrial process fluids.

Technical Configuration

Field Description Selected Option
Probe Type 330104 (3300 XL 8mm, M10x1 Thread, Armored)
Unthreaded Length 4.0 mm (Option 04)
Overall Case Length 10 mm (Option 10)
Total Cable Length 1.0 Meter / 3.3 Feet (Option 10)
Connector & Cable ClickLoc™ Connector, Armored Standard Cable (Option 02)
Agency Approval CN (Country Specific Approval)

Key Performance Features

  • Hybrid Threading Design: The 4 mm unthreaded tip section allows for easier insertion and clearance in specific machinery brackets while maintaining the strength of M10x1 threads.
  • Rugged Mechanical Shielding: Integrated stainless steel armor ensures the coaxial cable is protected from industrial wear, debris, and physical impacts.
  • Precise Signal Transfer: Features a nominal DC resistance of 7.59 ± 0.50 Ω for its 1.0m length, ensuring seamless compatibility with 3300 XL Proximitor® Sensors.
  • Metric Machinery Standard: Designed for international compatibility with metric mounting holes, avoiding the need for English-to-metric adapters.

Electrical & Environmental Specs

The 330104-04-10-10-02-CN probe is calibrated for an AISI 4140 steel target with a recommended gap setting of 1.27 mm (50 mils). It operates on a -24 Vdc supply and offers a stable output resistance of 50 Ω. The PPS tip material is specifically chosen for its chemical resistance and stability at high altitudes (up to 2000 meters) and across varying industrial temperatures.

Technical FAQs

Q1: Why choose a 4mm unthreaded length?
A1: The 04 option provides a smooth section at the tip of the probe, which is often required for specific machine mounting sleeves to prevent thread damage during installation.

Q2: Is a Certificate of Origin (COO) available for this model?
A2: Yes, as a genuine Bently Nevada product made in the U.S.A., a COO can be provided for your international documentation needs.

Q3: What makes the ClickLoc™ connector reliable?
A3: The ClickLoc system provides a vibration-resistant, self-locking coaxial connection that prevents accidental disconnection in high-vibration rotating machinery environments.

Condition: New & Original in Factory Packing

Warranty: 12 Months Factory Warranty
