330103-00-12-50-02-CN

330103-00-12-50-02-CN Bently Nevada M10x1 Metric Probe

På lager (16 enheter), klar til å sendes

  • Manufacturer: Bently Nevada

  • Product No.: 330103-00-12-50-02-CN

  • Product Type: Proximity Probe

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 323g

  • Shipping port: Xiamen

  • Warranty: 12 months

30 dagers returrett · 12 måneders garanti
  • Rask levering
  • 24/7 kundestøtte
  • Kvalitetssikring

Beskrivelse

Product Overview

The Bently Nevada 330103-00-12-50-02-CN is a high-precision, metric-series proximity probe from the 3300 XL 8mm family. Specifically designed for industrial machinery protection, this non-contact eddy current sensor monitors critical shaft vibration and position. With its M10x1 threaded body and extended 120mm case length, the 330103-00-12-50-02-CN provides stable, accurate data in narrow or deep-set installation environments, ensuring the safety and reliability of high-speed rotating equipment.

Technical Configuration

Detailed engineering parameters for this 3300 XL configuration:

  • Model Series: 3300 XL 8 mm Probe (Metric M10 x 1 thread)
  • Unthreaded Length (00): 0 mm
  • Overall Case Length (12): 120 mm
  • Total Length (50): 5.0 Meters (16.4 feet)
  • Connector (02): Miniature coaxial ClickLoc™ connector
  • Agency Approval (CN): Country-specific certified approvals
  • Armor: Without stainless steel armor

Technical Specifications

Requirement Detailed Specification
Operating Voltage 15 to 30 VDC
Frequency Range Up to 100 kHz
Temperature Range -40°C to +120°C (-40°F to +248°F)
Linear Range 2 mm (80 mils)
Unit Weight Approximately 0.323 kg
Material Stainless Steel Case / PPS Tip

Engineering Advantages

The 330103-00-12-50-02-CN stands out for its high-frequency response capabilities, supporting signals up to 100 kHz for precise monitoring of high-speed turbomachinery. The ClickLoc™ connector provides a secure, vibration-proof electrical connection that eliminates the need for manual tightening tools while preventing signal loss. This specific 5-meter version is designed to be paired with a corresponding 5-meter Proximitor Sensor, ensuring the entire transducer system maintains its factory calibration and linear accuracy.

Technical FAQs

Q1: What does the "CN" approval code signify?
A1: The "CN" designation indicates that this probe has been manufactured to meet specific regional or national regulatory standards required for operation in certain countries, ensuring compliance with local industrial safety laws.

Q2: Can I install this probe in a standard English-threaded housing?
A2: No. This model uses a metric M10x1 thread pattern. Attempting to install it in an English-threaded port (such as 3/8-24) will result in cross-threading and damage to the probe case.

Q3: Is this probe suitable for high-pressure environments?
A3: While 3300 XL probes include a Viton O-ring for differential pressure sealing between the tip and case, this model is not factory-tested for specific high-pressure limits. For high-pressure applications, please contact technical support for additional testing options.
