31000-16-10-00-085-03-02

31000-16-10-00-085-03-02 Bently Nevada 3300 XL 8mm Probe Case

På lager (14 enheter), klar til å sendes

  • Manufacturer: Bently Nevada

  • Product No.: 31000-16-10-00-085-03-02

  • Product Type: Housing Assembly

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 1200g

  • Shipping port: Xiamen

  • Warranty: 12 months

30 dagers returrett · 12 måneders garanti
  • Rask levering
  • 24/7 kundestøtte
  • Kvalitetssikring

Beskrivelse

Product Overview

The Bently Nevada 31000-16-10-00-085-03-02 is a professional-grade Proximity Probe Housing designed to protect sensitive 3300 XL 8 mm probes in harsh industrial environments. Manufactured in the USA, this housing is constructed from glass-reinforced Polyphenylene Sulfide (PPS) thermoplastic, providing exceptional resistance to chemicals and impact. This specific configuration features an 8.5-inch probe penetration and high-performance NPT fittings, making it ideal for vibration monitoring in hazardous or corrosive areas.

Technical Configuration

Detailed part number breakdown for precise system matching:

  • Brand: Bently Nevada (Baker Hughes)
  • Model: 31000-16-10-00-085-03-02
  • Probe Option (16): Compatible with 3300 XL 8 mm Probes
  • Cable Length (10): 1.0 Meter (39 inches)
  • Standoff Adapter (00): No standoff adapter included
  • Penetration (085): 8.5-inch Probe Penetration depth
  • Fittings (03): Two plugs, 3/4-14 NPT fitting, and cable seal grip
  • Mounting Thread (02): 3/4-14 NPT standard mounting

Technical Specifications

Requirement Detailed Specification
Unit Weight 1.2 kg (2.6 lbs) typical
Protection Ratings IP66 / CSA Type 4X / CENELEC EN50014
Temperature Rating -51°C to +105°C (-60°F to +221°F)
Impact Strength 4 Joule at extremes (-39°C to 115°C)
Housing Material Conductive fiber PPS Thermoplastic
Metallic Components AISI 303 & 304 Stainless Steel

Engineering Advantages

The Bently Nevada 31000-16-10-00-085-03-02 is engineered for maximum reliability in the field. The use of PPS thermoplastic containing conductive fibers ensures effective electrostatic dissipation, meeting CENELEC EN50014 standards for hazardous areas. Despite its lightweight 1.2 kg design, the housing is exceptionally strong, verified by CSA to withstand impacts of up to 7 Joules at room temperature. The inclusion of Neoprene® O-rings and stainless steel retaining chains ensures a long service life and IP66-rated protection against dust and water ingress, while the 29.4 N·m recommended torque for the retaining nut provides a secure, vibration-resistant installation.

Technical FAQs

Q1: What probes are compatible with the "16" option in the part number?
A1: The "16" option indicates that the housing is specifically machined and gapped for the Bently Nevada 3300 XL 8 mm proximity probe series.

Q2: Is this housing suitable for outdoor use in corrosive environments?
A2: Yes. With a CSA Type 4X rating and IP66 verification, this housing is specifically designed to resist corrosion and provide a watertight seal against rain, snow, and hose-directed water.

Q3: What cable sizes does the included cable seal grip support?
A3: The "03" fittings option includes grommets capable of sealing cable diameters ranging from 1/8 to 3/8 inches, covering standard proximity probe lead wire sizes.
